DEMO MANUAL DC116
HOT SWAP CONTROLLER
PC FAB DRAWI G
Linear Technology Corporation
12
1630 McCarthy Blvd., Milpitas, CA 95035-7417
(408) 432-1900 FAX: (408) 434-0507 www.linear-tech.com
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
U
DC116B
B
A
A
2.400
A
0.200
A
B
0.200
SYMBOL DIAMETER OF HOLES PLATED
A
B
C
D
E
F
TOTAL HOLES
NOTES: UNLESS OTHERWISE SPECIFIED
1. MATERIAL: 2 LAYERS, 0.062" THICK FR-4 GLASS EPOXY 2 OZ COPPER CLAD
2. ALL DIMENSIONS ARE IN INCHES ±0.003
3. PLATE THRU HOLES WITH COPPER 0.0014 MIN THICKNESS.
ALL HOLE SIZES IN HOLE TABLE ARE AFTER PLATING
4. SILSCREEN: WITH WHITE EPOXY NONCONDUCTIVE INK
5. FINISH: SMOBC
6. SOLDER MASK: LPI, GREEN
3.500
3.300
E
D
D
E
F
D
D
D
F
D
D
NUMBER
0.205 4 YES
0.125 4 YES
0.094 6 YES
0.060 8 NO
0.030 96 YES
0.025 4 YES
122
B
C
C
C
C
C
C
B
DC116B FAB
