on stage LPT6000 Assembly Instructions

ASSEMBLY INSTRUCTIONS
Multi-Purpose Laptop Stand
Congratulations on your purchase of the LPT6000 Multi-Purpose Laptop Stand. Please read
the following assembly instructions carefully. We hope you enjoy your new purchase!
Parts
Tools needed: Philips head screwdriver.
Remove all parts from boxes and identify:
Upper
Support (2)
Lower
Support (2) (2)
Support Assembly
1. Take one of the Upper Supports and place it
over the outside of one of the Lower Supports
(See Figure A). Align the Upper Support holes
with the Lower Support mounting holes to obtain
the desired height.
2. Place one knob at a time through the mounting
holes (must be spaced at least 2 holes apart).
3. Take a Stabilizer Bar and screw the top knob
into the end of the Stabilizer Bar. Repeat with
bottom knob.
4. Install 1 inch spacers on each Stabilizer bar to
increase stand width. Repeat Step 3 with the other
Upper Support and Lower Support for the opposite
side of the stand (see Figure B). Secure all knobs
tight to minimize stand wobble.
C-Clamps
(2)
Flat Stabilizer Spacers
Foot Bar (2)
Bar (2)
(2)
Knobs
(4)
Washers A Washers B
(8) (4)
Screws A Screws B
(8) (4)
Place Upper
support over
Lower support,
so that the
Upper Support
is on the
outside
of the stand
Knobs must
be spaced at least
Figure A
2 holes apart
Figure B
LPT6000
