GS5012
12-Space Ukulele Rack
Instruction Manual
Parts Included:
U-Brackets
x2
Long Hex
Bolts
x2
Assembly Instructions
Assembling as a Stand
1. Attach support leg to support
arm using one short hex bolt.
Tighten bolt securely. Flip over
so leg is on the ground. Repeat
for second pair.
Questions or Concerns? Contact the Customer Service Department
at cs@MusicPeopleinc.com or call us at (800) 289-8889.
©2019 The Music People
On-Stage.com
Yokes
x12
Nuts
x12
Short Hex
Hex
Bolts
Wrench
x2
x1
3. Attach cross bar
with U-bracket and
long hex bolt into one
support arm. Tighten
bolt securely.
Cross Bar
x1
Support Arms
x2
Wood Screws
x4
Wall Mount
Support Arms
x2
Wrench
x1
Support Legs
x2
Wall Mount
Support Legs
x2
2. Attach U-bracket to end cross bar
using one long hex bolt. Make sure
yoke holes are on the sides. Repeat
with second U-bracket on opposite end.
4. Insert one yoke into
cross bar. Fasten one
nut to opposite side
using wrench to
secure yoke.
5. Repeat step 4 for
remaining yokes and nuts.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for on stage GS5012
Summary of Contents for on stage GS5012
- Page 1 GS5012 12-Space Ukulele Rack Instruction Manual Parts Included: Cross Bar Support Arms Yokes Support Legs Wood Screws Nuts U-Brackets Wall Mount Support Arms Long Hex Short Hex Wrench Bolts Bolts Wrench Wall Mount Support Legs Assembly Instructions Assembling as a Stand 1.
- Page 2 Tighten bolt securely. 6. Attach assembled wall mount Wall support leg to wall. Be sure to use a stud finder or wall anchors to properly secure the GS5012. Completed Stand Completed Wall Mount...
