GB
Have the appliance serviced whenever
n
necessary.
Switch the appliance off when it is not in use.
n
Wear protective gloves.
n
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment's
construction and layout:
1. Lung damage if no suitable protective dust mask
is used.
2. Damage to hearing if no suitable ear protection is
used.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.

5. Before starting the equipment

Charge the battery pack with the charger supplied. An
empty battery pack requires a charging period of
approximately 1 hours.
For more details about charging the battery pack
please read the operating instructions of the 1-hour
charger.
Always remove the battery pack before making
adjustments to the equipment.
5.1 Mounting and removing the battery pack
(Fig. 2/Item 3)
Mounting:
Push the battery pack (3) onto the equipment until it
latches in place.
Removing:
Press the pushlock button (7) and pull the battery
pack (3) out of the equipment.
5.2 Changing the saw blade (Fig. 3)
Always switch off the saw and remove the battery
pack before working on the machine or changing the
saw blade.
Turn the ring (a) on the blade holder (6) as shown in
Fig. 3 until the blade (4) lets itself be slipped into the
slot of the blade holder (6).
When you now let go of the ring (a) again, the ring
(a) should return to its starting position.
If this fails to happen, try turning the ring (a) by hand
into its starting position.
6
Pull on the blade (4) to check whether it sits tightly in
the blade holder (6).

6. Operation

6.1 ON/OFF switch (Fig.1 /Item 1)
To switch on:
Press the locking button (2) and the ON/OFF switch
(1) at the same time
Allow the saw blade (4) to accelerate until it
reaches full speed. Then slowly move the saw
blade (4) along the cutting line. Only exert gentle
pressure on the saw blade as you do so.
To switch off:
Release the locking button (2) and ON/OFF switch (1)
If you release the ON/OFF switch (1) the
equipment will shut down automatically which
means that it cannot operate accidentally.
Ensure that you do not cover or block the
ventilation openings whilst working with the tool.
Do not slow down the saw blade after you switch
it off by pressing it sideways.
Important! Do not put down the machine until the
saw blade has reached a complete standstill.
Important. Carry out a trial cut in a piece of
waste wood
6.2 Use as a jigsaw (Fig. 4)
Place the All purpose saw on the material to be cut
as shown in Fig. 4. Switch on the All purpose saw
and push it along against the material to be cut.
Adapt your cutting speed to the material.
