2. Layout / Items supplied (Fig. 1/2)
2.1 Layout
1 ON/OFF switch
2 Locking button for ON/OFF switch
3 Battery Pack
4 Saw blade
5 Soleplate
6 Blade holder
7 Pushlock button
2.2 Items supplied
Open the packaging and take out the equipment
n
with care.
Remove the packaging material and any
n
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
n
Inspect the equipment and accessories for
n
transport damage.
If possible, please keep the packaging until the
n
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of
swallowing or suffocating!
Cordless All Purpose Saw
n
Saw blade (1x)
n
Original operating instructions
n
charger (1x in set included)
n
Battery Pack (2x in set included)
n
3. Proper use
The All purpose saw is designed for sawing wood,
non-ferrous metals and plastic. It should only be
used with the appropriate saw blade.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Voltage supply:
Stroke rate: 0-3000 rpm
Stroke height:
Cutting depth, wood:
Weight:
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L sound pressure level
pA
K uncertainty
pA
L sound power level
WA
K uncertainty
WA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Cutting in Wood
2
Vibration emission value a h = 18.708 m/s
K uncertainty = 1.5 m/s 2
Additional information for electric power tools
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equipment
is used and may exceed the specified value in
exceptional circumstances.
The specified vibration value can be used to compare
the equipment with other electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
n
order.
Service and clean the appliance regularly.
n
Adapt your working style to suit the appliance.
n
Do not overload the appliance.
n
GB
18V d.c.
22mm
100mm
2.0 kg
92 dB(A)
3 dB
103 dB(A)
3 dB
