INSTALLER:
1. Affix these instructions or adjacent to water heater.
2. Before leaving premises: REVIEW this operation,
installation and service manual to be sure heater has been installed correctly.
Make sure unit is started and operated for one complete cycle and water
temperature is acceptable to he costumer at the fixtures.
1120287 - REV. AUG 19
Operating, installation
and service manual
Standard Residential power vent
Gas Water Heater with vaporshield Technology.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
1. Do not try to light any appliance.
2. Do not touch any electrical switch; do not use any
phone in your building.
3. Immediately call your gas supplier from a neighbor´s phone.
Follow the gas supplier´s instructions.
4. If you can not reach your gas supplier, call the fire department.
Installation and service must be performed by a qualifed installer, service agency or the
gas supplier.
THIS WATER HEATER SHALL NOT BE INSTALLED IN BATHROOMS, BED-
ROOMS, OR ANY OCCUPIED ROOM NORMALLY KEPT CLOSED.
VAPORSHIELD® Technology Gas Water Heatersmeet the new ANSI Z21.10.1
standard that deals with the accidental or unintended ignition of flammable vapors,
such as those emitted by gasoline.
WARNING: This water heater is equipped for one type of gas only. Check
the data plate near the gas control valve for the correct gas. DO NOT USE THIS
WATER HEATER WITH ANY GAS OTHER THAN THE ONE LISTED ON THE
DATA PLATE. Failure to use the correct gas can cause problems which can result
in DEATH, SERIOUS BODILY INJURY OR PROPERTY DAMAGE. If you have any
questions or doubts consult your gas supplier or gas company. Water heaters for
bottled, propane or liquefied petroleum gas (LPG) are different from natural gas
models. A natural gas heater will not function safely on bottled, propane or lique-
fied petrolum gas (LPG) and no attempt should be made to convert a heater from
natural gas to any other gas.
OWNER:
1. Retain these instructions and warranty for future
reference.
All technical and warranty questions should be directed to the local dealer from
whom the water heater was purchased. If you are unsuccessful please write to
the company listed on the warranty or data plate which came with your water
heater.
CALL THIS TOLL FREE NUMBER 1-888-883-0788
WITH ANY QUESTIONS DURING OR AFTER INSTALLATION.
HAVE YOUR MODEL AND SERIAL NUMBER AVAILABLE BEFORE
CALLING.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American Standard Standard Residential
Summary of Contents for American Standard Standard Residential
- Page 1 Operating, installation and service manual Standard Residential power vent Gas Water Heater with vaporshield Technology. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: General Safety
GENERAL SAFETY Read and undestand instruction manual and safety message before installing, operating or servicing this water heater. Failure to follow instructions and safety messages could result in death or serious injury. Instruction manual must remain with water heater. For continued proctection against risk or fire: •... -
Page 3: Table Of Contents
CONTENTS ABLE OF General safety Table of contents, installation information Consumer responsibilities Location clearances from combustible construction Typical Installation Air supply, all air from inside the building, all air from Outside the building 4, 5 Mechanical exhausting and fireplaces Venting, water piping, caution operating an empty or partially filled water, closed water systems Temperature and pressure relief valve Space heating / potable water system... -
Page 4: Consumer Responsibilities
CONSUMER RESPONSIBILITIES THIS MANUAL HAS BEEN PREPARED TO ACQUAINT YOU WITH THE INSTALLATION, OPERATION AND MAINTENANCE OF YOUR GAS WATER HEATER AND TO PROVIDE IMPORTANT SAFETY INFORMATION. WE URGE YOU TO READ ALL INSTRUCTIONS THOROUGHLY before attempting installation or operation of your water heater. - Page 5 WARNING When this heater is installed directly on caepeting, carpeting THIS MANUAL HAS BEEN PREPARED TO must be protected by a metal or wood panel beneath the ACQUAINT YOU WITH THE INSTALLATION, appliance extending beyond the full width, and depth if the OPERATION AND MAINTENANCE OF YOUR GAS appliance is installed in an alcove or closet, the entire floor WATER HEATER AND TO PROVIDE IMPORTANT.
-
Page 6: Typical Installation
INSTALLATION TYPICAL CLOSED WATER SYSTEM EXPANSION PRESSURE REDUCING TANK VALVE WITH BYPASS HOT OUTLET WATER COLD COLD WATER WATER INLET INLET VALVE TEMPERATURE AND PRESSURE RELIEF VALVE **SOME MODELS MAY HAVE TEMPERATURE & PRESSURE RELIEF VALVE TAPPING ON TOP OF HEATER DATA PLATE AND LIGHTING INSTRUCTION LOCATION GAS CONTROL VALVE (THERMOSTAT) - Page 7 ALL AIR OUTDOORS AIR SUPPLY FROM Important air for combustion and ventilation must not come from a The confined space shall be provided with corrosive atmosphere. Any failure due to corrosive elements in the two permanent openings, one commencing atmosphere is exclude from warranty coverage. within 12 inches of the top and one commencing within 12 inches of the The following types of installation...
-
Page 8: Mechanical Exhausting And Fireplaces
NOTE: If the equipment room is located against an outside wall and the air openings communicate directly with the outdoors, each opening shall have a free area of not less than one square inch per 4,000 BTU FIGURE 8 per hour of the total input rating of all UPPER Equipment Located in Confined Spaces;... -
Page 9: Temperature And Pressure Relief Valve
VENT PIPE SIZE It is important that you follow the guidelines in these instructions for sizing a vent pipe system. If a transition to a larger vent size is required, the vent transition connection must be made at the blower outlet. VERTICAL EXHAUST GAS VENT Vertical exhaust gas vents must be installed with U.L. - Page 10 TEMPERATURE & PRESSURE RELIEF VALVE For protection against excessive pressures and/or temperatures, a temperature and pressure relief valve must be installed in the opening marked, “temperature and pressure relief valve”. A design certified by a nationally recognized testing laboratory that maintains periodic inspection of production of listed equipment or materials, as meeting the requirements for Relief Valves and Automatic Gas Shut-Off Devices for Hot Water Supply Systems, Z21.22 is furnished with this water heater.
-
Page 11: Space Heating/Potable Water System
T&P Relief Valve and Pipe Insulation. (Only Models with insulation material included in the package) 1. Locate the T&P Relief Valve on the Water Heater. 2. Locate the slit running the lenght of the insulation. 3. Spread this slit open and slip it over the T&P Relief Valve (See Figure 10). Apply gentle pressure to the insulation to ensure it is fully seated on the T&P Relief Valve. - Page 12 DO NOT use this water heater as a replacement for an existing boiler installation. DO NOT use with piping that has been treated with chromates, boiler seal or other chemicals. DO NOT add boiler treatment or any chemicals to any heat piping, since the piping contains potable water. DO NOT use with ferrous piping.
-
Page 13: Termination Clearances Sidewall
TERMINATION CLEARANCES SIDE WALL POWER VENT Note: The following picture and table are intended to illustrate clearance requirements, and do not serve as a substitute for locally adopted installation codes. INSIDE CORNER DETAIL VENT TERMINAL AIR SUPPLY INLET AREA WHERE TERMINAL IS NOT PERMITTED FIXED CLOSED Fig. -
Page 14: Blower Assembly Installation
BLOWER ASSEMBLY INSTALLATION WIRING DIAGRAM This power vented water heater comes with blower assembly BLOWER installed (see Figure 12). After unit is set in place, make sure blower assembly is still mounted securely. Make sure there is no damage to blower. HOSE CONNECTION PLUG... -
Page 15: Installation Vent System 11 To
g. Close the panel on the junction box. Make sure the access panel is properly secured. 6. The blower discharge coupling boot is made to accept only straight sections of 2” pipe. To start off with an elbow, a short section of the straight pipe must be cut and glued into the end of the elbow that will mount on the discharge boot. - Page 16 POLYPROPYLENE VENT SYSTEMS Note: This cap must remain in place if a drain hose is not installed. Polypropylene vent systems do not use cement to connect the pipe and elbow sections but use a push together gasket seal method. EXHAUST VENTING Do not attempt to connect polypropylene with sealant cement.
- Page 17 IMPORTANT NOTES AND WARNINGS • This heater is certified to be installed using PVC, CPVC, ABS How to determine the “equivalent length” is shown in Figure or polypropylene plastic vent material. Check with your local in Table 1. authorities to determine which materials are allowed in your area.
- Page 18 Calculating Equivalent Feet Important: Use of cellular core PVC (ASTM F891), cellular core CPVC, or Radel® (polyphenylsulfone) in non-metallic venting systems is prohibited WATER HEATER VENT SIZE PRESSURE MAXIMUM EQUIVALENT MINIMUM EQUIVALENT HEATER INPUT (Inside Diam.) SWITCH VENT LENGTH VENT LENGTH MODEL (Btu/hr.) SETTING...
- Page 19 Venting instructions 11. Do not seal the vent piping to the wall until the venting is Plan the venting layout starting at the vent termination and properly connected to the blower assembly. work back toward the heater. Take into consideration the 12.
- Page 20 2" VENT PIPE 3 in. MIN. TERMINATION LENGTH MAY BE 90° CONFIGURATION FOR 40 AND 50 ELBOW GALLON (LO-INPUT) HEATERS A VENT USED IN A 2" RUBBER CONNECTED TO 2" VENTING. COUPLING SPECIAL VENTING (SUPPLIED) SYSTEM WITH POSITIVE VENT PRESSURE AND PASSING THROUGH A 18 in.
- Page 21 VENT PIPE PREPARATION WARNING 1. INITIAL PREPARATION • Make sure the solvent cement you are planning to use is Fire Hazard designed for the specific application you are attempting. •Primers and cements are • Know the physical and chemical characteristics and limitations extremely flammable, and must of the PVC and CPVC piping materials that you are about to not be stored or used near heat or...
- Page 22 Applicators: B. Deburring Use a knife, plastic pipe deburring tool, or file to remove burrs Select a suitable pure bristle type paint brush. from the end of small diameter pipe. Use a proper width brush or roller to apply the primer and Be sure to remove all burrs from around the inside as well as cement (see chart below).
- Page 23 E. Application of solvent cement G. Cleanup and joint movement • Apply solvent cement evenly an quickly around outside of pipe Remove all excess cement from around the pipe and fitting with at a width a little greater than the depth of the fitting socket. a dry cotton rag.
-
Page 24: Installation Checklist
INSTALLATION CHECKLIST Vertical Note: Use and complete this checklist before lighting the heater. Correct any conditions that do not meet these 〇 Exhaust vent termination 18” min. above roof/snow level. instructions. 〇 Correct termination screen installed and secured. Water Heater Location Water System Piping 〇... - Page 25 SOLAR INSTALLATION When this appliance is used AS A SOLAR STORAGE HEATER OR AS A BACK UP FOR THE SOLAR SYSTEM, the following warning applies. WARNINGS CAUTION INSULATION BLANKET Water supply to this heater must not Insulation blanket kits which area available for external applications to water exceed 180ºF.
- Page 26 SAFETY READ OPERATING FOR YOUR BEFORE WARNING: If you do not follow these instrutions exactly, a fire or explosión may result causing property damage, personal injury or loss of life. A. This appliance does not have a pilot. It is equipped •...
- Page 27 GAS REQUIREMENTS Read the data plate to be sure the water heater is made for the type of gas you will be using in your home. This information will be found on the data plate located near the gas control valve. If the information does not agree with the type of gas available, do not install or light.
-
Page 28: Removing And Replacing The Gas Control Valve/Thermostat
WARNING DO NOT OPERATE APPLIANCE UNTILL ALL LEAKAGE IS CORRECTED. DO NOT USE OPEN FLAME OR ANY KIND OF SPARK TO CHECK FOR LEAKS. REMOVING REPLACING THE GAS CONTROL VALVE/THERMOSTAT Important: The gas control is an electronic valve: To replace the electronic gas valve, reassemble in re- verse order: •... -
Page 29: Replacing The High Temperature Cut Off Switch Assembly
REPLACING THE HIGH TEMPERATURE CUT OFF SWITCH ASSEMBLY Your American Standard VAPOR SHIELD water heater is 1. Run a jumper wire across the two spade connectors on equipped with a high temperature cut off switch that is provided the switch to determine if the switch is still in the open to shut down the water heater when the incoming air is position. -
Page 30: Burner Maintenance/Replacement
REMOVAL BURNER OF THE ASSEMBLY BURNER ADJUSTMENT There are no adjustments to this water heater (other than water temperature selection). The electronic valve (gas control valve) is equipped for total regulation of the main burner. BURNER MAINTENANCE At least once a year a visual inspection should be mande of the main burner and hot surface ignitor. You should check for sooting, soot is not normal and will impair proper combustion. -
Page 31: Draining And Flushing Interior Of Tank
DRAINING FLUSHING INTERIOR OF TANK The water heater should be drained if being shut down during freezing temperatures. Also periodic draining and cleaning of sediment from the tank may be necessary. 1. “TURN OFF GAS TO APPLIANCE” (Figure 4). 2. Close the cold water inlet valve to the heater (Figure 4). - Page 32 EMERGENCY SHUT DOWN Should overheating occur or the gas supply fail to shut off, turn off the manual gas control valce to the appliance and call a qualified service person to check for the cause. WARNING Stacking Stacking occurs when a series of shorts draws of hot water are taken from the water heater tank.
- Page 33 WARNING HYDROGEN GAS Hydrogen gas can be produced in water system that has not been used for a long period of time HYDROGEN GAS IS EXTREMELY FLAMMABLE. To prevent the (generally two weeks or more). possibility of injury under these conditions, we recommend the hot water faucet be open for several minutes at the kitchen sink before you use any electrical appliance which is connected to the hot water system.
- Page 34 SERVICE MUST BY A QUALIFIED INSTALER, BE PERFORMED SERVICE AGENCY OR GAS SUPPLIER THE FOLLOWING IS A LIST OF THE MOST COMMON COMPLAINTS RELATED TO THE USE OF WATER HEATERS. MANY COMPLAINTS ARE DUE TO ITEMS NOT DIRECTLY RELATED TO THE WATER HEATER. DO NOT ATTEMPT TO SERVICE THE WATER HEATER OF PERFORM OTHER RECOMMENDATIONS ON THIS LIST UNLESS YOU ARE TRAINED AND QUALIFIED TO DO SO.
-
Page 35: Troubleshooting Check List
TROUBLESHOOTING CHECK LIST PROBLEM POSSIBLE CAUSE(S) CORRELATIVE ACTION GAS CONTROL LED of flammable vapors sensor FVS on the Call service number on front of this VALVE AND Electrical Switch remain lit manual. BLOWER WITH OUT LED of high temperature cut off switch TOD on Call service number on front of this the Electrical Switch remain lit manual. - Page 36 TROUBLESHOOTING CHECK LIST GAS CONTROL Defective gas control valve Replace gas control valve. VALVE FAILS TO Improper calibration Replace gas control valve. SHUT OFF Chlorination procedure. Sulfides in water supply Chlorination procedure. SMELLY WATER Bacteria in water supply Replace with anode appropiate for water Incompatible anode conditions.
- Page 37 TROUBLESHOOTING CHECK LIST Plug in power cord, check fuses and/or No power to unit supply voltage. Gas control valve set too low Turn temperature knob to higher setting. Defective air pressure switch Replace air pressure switch. Defective blower Replace blower. Disconnected or loose wire Repair and reconnect wires.
- Page 38 RESETTING THE HEATER CONNTROL • Soft lockouts as diagnosed by the system error codes require the gas control to be reset. • To reset the control, slide the “ON/OFF” switch to the “OFF” position. Wait fot 10 seconds and move the switch back to the “ON” position. •...
- Page 39 IGNITION STATE TIMING LED FLASH CONTROL IGNITION STATE TIMING SEQUENCE STATUS 5 seconds (NG models) Pre-purge Short flash once IDLE (no call for heat, 15 seconds (LP models) every four seconds no fault conditions) Hot Surface Igniter 10 seconds “Heartbeat”, Call for Heat (HSI) Warmup alternates bright/dim...
-
Page 40: Reading The Led Flash Sequence
READING LED FLASH SEQUENCE The LED indicator light is active when the gas valve is in operation. The light will normally show a flash sequence of a short flash once every four seconds or a “Heartbeat” of alternating bright/dim. Multiple flash codes indicate an error and can be read as follows: Example: Corrective Action Number 9, Six-Two Flash, three second pause. - Page 41 CORRECTIVE ACTION CORRECTIVE ACTION NUMBER Gas supply is turned off or gas pressure is too low. Ensure supply pressure and manifold gas pressures are within requirements. Manifold pressure is nonadjustable, if gas supply pressure proves correct and manifold pressure is off by more than 0.3” WC replace the control. Low supply voltage - should be 115 - 125 VAC Ensure flame sensor is making good contact with the burner flame and flame is steady.
-
Page 42: Repair Parts Illustration
REPAIR ILLUSTRATION PARTS ITEM PARTS DESCRIPTION BLOWER 2. TEMPERATURE SWITCH (NOT SHOWN) 3. PRESSURE SWITCH (NOT SHOWN) 4. BAFFLE 5. COLD WATER DIP TUBE 6. HEAT TRAMP (SOME MODELS) 7. ANODE ROD (NOT SHOWN) 8. TEMPERATURE & PRESSURE RELIEF VALVE 9. - Page 44 2. Should your problem not be solved to your complete satisfaction, you should then contact the Manufacturer’s Service Department at the following address: American Standard Water Heaters 561 New York drive Pomona, CA, 91768 1-888-883-0788 When contacting the manufacturer, the following information will be requested: a.
