- Page 1 PX800-C PxArt+ 06 Ceiling PxArt+ 12 Ceiling PxArt+ 18 Ceiling User manual...
-
Page 2: Table Of Contents
8 DMX signal connecting................15 9 Connection scheme.................16 10 Dimensions.....................17 11 Technical data..................18 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description PX800-C is a professional LED illuminator designed for illumination of museum exhibitions or displays. Thanks to the application of the most modern semiconductor SSL LED light sources and advanced control electronics, a high class illuminator was created which meets very high requirements for museum and exhibition lighting. -
Page 4: Safety Conditions
Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard LED light emission,... - Page 5 The PX800-C device is powered directly from 230V power grid. Failure to comply with the safety rules may result in electric shock and may endanger the user’s life. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual.
-
Page 6: Connectors And Control Elements
Connectors and control elements Brightness adjustment Color temperature adjustment PX277 parameter programming connector Information on version Below is a description of the PX 800-C model designations with their explanation PX800-C – AA – XX – Z AA – version: XX – beam angle: Z –... -
Page 7: Control
Control 5.1 Buttons The lamp has been equipped with buttons which allow for changing the brightness level and color temperature of light. The buttons have been placed at the bottom part of the junction box, above the lamp reflector. One button is responsible for one parameter. - Page 8 It is possible to change the adjustment direction without reaching extreme values. For example, while the lamp brightness is increased, release the control button for a moment. The diode will signal the change of adjustment direction. The pressing of the adjustment button again will cause the dimming of the lamp (brightness decrease).
-
Page 9: Dmx Signal
5.2 DMX signal The PX800-C lamp can be controlled via two DMX channels: • Channel 1 – color • Channel 2 – brightness Setting the lamp parameters: Value of the lamp parameter Value of the DMX signal 4500K Adjusting the color 3600K temperature 2700K... -
Page 10: Cooperating With The Px277 Configurator
Cooperating with the PX277 configurator Lamp settings can be changed by connecting the PX277 configurator (PxArt+ Settings Controller) to it. It allows in connection with PX800-C to define the following parameters: DMX addresses for color and brightness separately (in the range of 1 – 512) and device behavior in the absence of DMX signal (programmable scene). - Page 11 Driver temp. – a list of the lowest, highest and current operating temperature of the power supply, Module temp. – a list of the lowest, highest and current operating temperature of the module with LEDs, PWR time / ACT time – total lamp operation time / total lamp lighting time, Factory Default –...
-
Page 12: Scheme Of The Px800-C Menu In Px277
6.2 Scheme of the PX800-C menu in PX277 PX800-06 PX800-12 DMX Addr. PX800-18 PxArt+ 06 PxArt+ 12 PxArt+ 18 001 000 (2ch) ** NEXT PREV ENTER ENTER ENTER DMX Addr. DMX Addr. DMX Addr. DMX Addr. DMX Addr. 001 (2ch) 001 (2ch) * 001 002 (2ch) 001 002 (2ch) *... -
Page 13: Rdm - Available Parameters
RDM – available parameters The PX800-C supports the DMX-RDM protocol. DMX protocol allows only of a one-way data transmission, while extension the RDM protocol can transmit information in two directions. This makes possibility of monitoring activities of the compatible devices. Thanks to RDM some available settings of compatible devices may be programmed using this protocol. - Page 14 Parameter name Description FACTORY_DEFAULTS 0x0090 device default settings PERSONALITY * 0x00E0 DMX operational mode PERSONALITY_ description of individual 0x00E1 DESCRIPTION operational modes information on the selected SENSOR_DEFINITION 0x0200 temperature sensor SENSOR_VALUE 0x0201 information about sensors SMOOTH_OFF/1/2/3/4 * 0x801A selection of smoothing options NO_SIGNAL_OFF/ON/HLD/S behavior of the device when the 0x801C...
-
Page 15: Dmx Signal Connecting
DMX signal connecting PX800-C must be connected to the DMX line in series, without branching on the control cable. This means that the control cable should be connected to the DMX pins in the PX800-C, and then from the DMX pins to the next DMX receivers (diagram below). -
Page 16: Connection Scheme
Connection scheme DMX controller 230V AC PX800-C PX800-C Max. 32 devices on the line PX800-C Terminator (120 Ohm resistor) -
Page 17: Dimensions
10 Dimensions PxArt+ 06 Ceiling PxArt+ 12 Ceiling Ø122 Ø92 Ř149... -
Page 18: Technical Data
PxArt+ 18 Ceiling Ø149 11 Technical data type PX800-C power supply 230V AC number of diodes 6 / 12 / 18 wersja DW PX800-C-06: 10W power consumption PX800-C-12: 17,5W PX800-C-18: 25W max. temperature rise housing +30°C PX800-C-06: 600lm luminous flux PX800-C-12: 1200lm wersja MONO PX800-C-18: 1800lm... - Page 19 LEDs lifespan 50000h 10°, 20°, 30°, 40°, EL* (10 x 45°), WW** beam angle (50 x 110°) color temperature 2700 – 4500K (6000K on order) range of brightness adjustment 0 – 100% CRI index min. 90 control DMX, RDM programmable scenes mounting to the ceiling available housing colors...
- Page 20 Podłęże, 01.10.2020 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxArt+ 06/12/18 Ceiling Product code: PX800-C meets the requirements of the following standards, as well as harmonised standards: PN-EN 60598-1:2015-04...
