- Page 1 PX800-T PxArt+ 06 Track PxArt+ 12 Track PxArt+ 18 Track User manual...
-
Page 2: Table Of Contents
8 RDM – available parameters..............14 9 Connection scheme.................16 10 Dimensions.....................17 11 Technical data..................18 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description PX800-T is a professional LED illuminator designed for illumination of museum exhibitions or displays. Thanks to the application of the most modern semiconductor SSL LED light sources and advanced control electronics, a high class illuminator was created which meets very high requirements for museum and exhibition lighting. -
Page 4: Safety Conditions
Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard LED light emission,... - Page 5 The PX800-T device is powered directly from 230V power grid. Failure to comply with the safety rules may result in electric shock and may endanger the user’s life. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual.
-
Page 6: Connectors And Control Elements
Connectors and control elements Brightness adjustment Color temperature adjustment PX277 parameter programming connector Information on version Below is a description of the PX 800-T model designations with their explanation PX800-T – AA – XX – Z AA – version: XX – beam angle: Z –... -
Page 7: Dmx Connection
DMX connection PX800-T is a device attached to the GLOBAL Trac ® Pulse Control rail by using the GAC 600 adapter included in the kit. 5.1 GLOBAL Trac ® GAC 600 adapter DMX contacts DMX - (on the opposite side DMX +) MAINS POWER SUPPLY protective phase 1 (on the opposite... -
Page 8: Control
Control 6.1 Buttons The lamp has been equipped with buttons which allow for changing the brightness level and color temperature of light. The buttons have been placed at the bottom part of the junction box, above the lamp reflector. One button is responsible for one parameter. - Page 9 It is possible to change the adjustment direction without reaching extreme values. For example, while the lamp brightness is increased, release the control button for a moment. The diode will signal the change of adjustment direction. The pressing of the adjustment button again will cause the dimming of the lamp (brightness decrease).
-
Page 10: Dmx Signal
6.2 DMX signal The PX800-T lamp can be controlled via two DMX channels: • Channel 1 – color • Channel 2 – brightness Setting the lamp parameters: Value of the lamp parameter Value of the DMX signal 4500K Adjusting the color 3600K temperature 2700K... -
Page 11: Cooperating With The Px277 Configurator
Cooperating with the PX277 configurator Lamp settings can be changed by connecting the PX277 configurator (PxArt+ Settings Controller) to it. It allows in connection with PX800-T to define the following parameters: DMX addresses for color and brightness separately (in the range of 1 – 512) and device behavior in the absence of DMX signal (programmable scene). - Page 12 Driver temp. – a list of the lowest, highest and current operating temperature of the power supply, Module temp. – a list of the lowest, highest and current operating temperature of the module with LEDs, PWR time / ACT time – total lamp operation time / total lamp lighting time, Factory Default –...
-
Page 13: Scheme Of The Px800-T Menu In Px277
7.2 Scheme of the PX800-T menu in PX277 PX800-06 PX800-12 DMX Addr. PX800-18 PxArt+ 06 PxArt+ 12 PxArt+ 18 001 000 (2ch) ** NEXT PREV ENTER ENTER ENTER DMX Addr. DMX Addr. DMX Addr. DMX Addr. DMX Addr. 001 (2ch) 001 (2ch) * 001 002 (2ch) 001 002 (2ch) *... -
Page 14: Rdm - Available Parameters
RDM – available parameters The PX800-T supports the DMX-RDM protocol. DMX protocol allows only of a one-way data transmission, while extension the RDM protocol can transmit information in two directions. This makes possibility of monitoring activities of the compatible devices. Thanks to RDM some available settings of compatible devices may be programmed using this protocol. - Page 15 Parameter name Description FACTORY_DEFAULTS 0x0090 device default settings PERSONALITY * 0x00E0 DMX operational mode PERSONALITY_ description of individual 0x00E1 DESCRIPTION operational modes information on the selected SENSOR_DEFINITION 0x0200 temperature sensor SENSOR_VALUE 0x0201 information about sensors SMOOTH_OFF/1/2/3/4 * 0x801A selection of smoothing options NO_SIGNAL_OFF/ON/HLD/S behavior of the device when the 0x801C...
-
Page 16: Connection Scheme
Connection scheme 3-phase GLOBAL Trac® Pulse Control bus-bar end feed power supply cable DMX+ DMX- DMX wire (2 wires in screen) GLOBAL Trac® GAC600 adapter... -
Page 17: Dimensions
10 Dimensions PxArt+ 06 Track PxArt+ 12 Track Ø 92... -
Page 18: Technical Data
PxArt+ 18 Track ø148 11 Technical data type PX800-T power supply 230V AC number of diodes 6 / 12 / 18 PX800-T-06: 10W power consumption PX800-T-12: 17,5W PX800-T-18: 25W max. temperature rise housing +30°C PX800-T-06: 600lm luminous flux PX800-T-12: 1200lm PX800-T-18: 1800lm LEDs lifespan 50000h... - Page 19 10°, 20°, 30°, 40°, EL* (10 x 45°), WW** beam angle (50 x 110°) color temperature 2700 – 4500K (6000K on order) range of brightness adjustment 0 – 100% CRI index min. 90 control DMX, RDM programmable scenes mounting GLOBAL Trac ®...
- Page 20 Podłęże, 01.10.2020 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxArt+ 06/12/18 Track Product code: PX800-T meets the requirements of the following standards, as well as harmonised standards: PN-EN 60598-1:2015-04...
