Replacement of flywheel
Models: Echelon Row
Step 7.
Step 8.
Step 9.
Assemble the belt on coil,
Tighten nut(13) on main
Make sure the belt in the
make sure the direction as the
frame
middle of flywheel axle
picutre while spin the flywheel
Step 10.
Step 11.
After belt on the coil,
Check D- screw thread distance 17mm~18mm
tighten nuts (13) again
on main frame
Step 12.
Step 13.
Step 14.
Belt should be one straight
Tighten nuts(8) on main
on the coil flywheel and
frame
pulley
Check everything is
functional then
assemble the cover.
