Neptune R900 Pocket Reference

Reading Modes
Function Explanation
Normal Normal Mode is used to connect through
Bluetooth to a host device. Selection
between Route (filtered) and RF Test
(unfiltered) is made in the host device
software.
To enter this mode from other modes:
MODE
1 Press until the Mode LED flashes
.
ENT
2 Press , and the Mode LED turns
.
Unattended Unattended Operations Mode can operate
using the battery or when connected to
vehicle power.
To use this mode with battery power:
MODE
1 Press until the Mode LED is
.
ENT
2 Press .
To use this mode when connected to vehicle
power:
MODE
1 Press until the Mode LED is
.
ENT
2 Press and release.
ENT
3 Press again and hold for five
seconds, then release.
The Mode LED is
4 Connect the USB.
Note: The USB charger must be capable of
supplying 1A of current.
USB The SD card appears as an external drive to
mass storage
the PC.
To enter this mode:
1 Connect the USB to the R900 BCR and to
2 Press
3 Press
Accessing the R900 BCR Status Screen
The R900 BCR must first be set to Normal Mode to access the
R900 BCR Status Screen.
While in route Neptune Key, System, UTILS, AMR Status =
From the TAB twice, UTILS, Belt Clip Status =
Synchronize screen
Technical Support
Call us with your (800) 647-4832
question - normal
business hours
FAX your question (334) 283-7497
E-mail a question hhsupp@neptunetg.com
.
the PC.
Note: The USB must be connected
before the unit can enter the USB mass
storage mode.
MODE
until the Mode LED flashes
.
ENT
.
The SD card now shows as an external
drive attached to the PC.
, , ,
8
8 2
, ,
8
4
PRC R900 BCR 11.13
Part No. 13326-002
for the R900
®
Handheld Controls
Front view
Bluetooth RF Test
Battery door
Top view Buttons
For... Press...
ON Press for two seconds.
OFF Press for two seconds.
Setting Date/Time The R900 Belt Clip Receiver (R900 BCR)
®
sets time with the Trimble
when the two are paired. This time comes
from the last Nomad synchronization.
Pocket Reference
Belt Clip Receiver
Mode Power
SD/USB
Nomad (Nomad)
® ®
