UC305W User Guide
UCx 4.5
UC305W User Guide
This document contains proprietary and confidential information of E-MetroTel LLC. and shall not be used,
disclosed or reproduced, in whole or in part, for any purpose other than to install the UCX solution, without
the prior written consent of E-MetroTel. Title in and to this document and all information contained herein
remains at all times the property of E-MetroTel LLC.
E-MetroTel(R), LLC is privately held and headquartered in Dallas, Texas with offices in Canada, United
Kingdom and the Czech Republic. E-MetroTel provides Unified Communications, Call Centre/IVR, custom
applications products and services to businesses of all sizes. It specializes in Nortel and Avaya solutions and
has expertise in all areas of Unified Communications, Contact Centre, IVR, Speech recognition, CTI,
Workforce Management and CRM integration. Increasingly companies around the world are turning to
E-MetroTel for better value, a higher level of support and knowledge than they have seen from their
traditional providers.
Property of E-Metrotel 2014.
11-Feb-2015
Page
1
of
35
Copyright © 2014 E-Metrotel
Global Inc.
