  • Page 1 User Guide Sentrius RG191+LTE Version 1.1...
  • Page 2 EVISION ISTORY Ver. Date Notes Contributor(s) Approver 22 June 2020 Initial Release Chris Boorman 26 June 2020 Update for Certs Chris Boorman https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 3: Table Of Contents

    8.2.4 Connection Status .............................. 21 Senet ..................................22 Semtech Legacy UDP Forwarder ..........................22 8.4.1 Mode .................................. 22 8.4.2 Configuration ..............................23 https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 4 FCC Interference Statement ............................. 50 FCC Warning ..................................50 ISED Radiation Exposure Statement ..........................51 Labels ....................................52 12.1 RG191+LTE ................................52 https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 5 Sentrius RG191+LTE User Guide https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 6: About This Guide

    Laird’s Sentrius™ RG191+LTE LoRa-Enabled Gateway is the ultimate in secure, scalable, robust LoRa solutions for end-to- end control of your private LoRaWAN network. Leveraging Laird’s field-proven and reliable 50 Series Wireless Bridge certified module, it also offers enterprise dual-band Wi-Fi and wired Ethernet for complete design freedom. Based on the Semtech SX1301/SX1257 chipset designs, it offers a LoRa range up to ten miles and pre-loaded LoRa Packet Forwarder software, perfect for highly scalable, flexible IoT networks.

  • Page 7: Specification

    -91 dBm 54 Mbps -74 dBm (PER <= 10%) 802.11n (2.4 GHz) 6.5 Mbps (MCS0) -91 dBm 65 Mbps (MCS7) -71 dBm https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 8 IC – Contains IC ID: 31347A-1001 FCC – Contains FCC ID: SQG-RG191NALTE IC – Contains IC ID: 3147A-RG191NALTE Wi-Fi Antenna Model Laird MAF94051 Type Dipole https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 9: Ordering Information

    RP-SMA Antenna Gain 2.1 dBi (2.4-2.5 GHz), 2.4 dBi (4.9 GHz) 2.6 dBi (5.25 GHz), 3.4 dBi (5.875 GHz) LoRa Antenna Model Laird 001-0002 (902-928 MHz) used with RG191+LTE Type Dipole Connector RP-SMA Antenna Gain 2.0 dBi (863-870 MHz) used with RG186 2.0 dBi (902-928 MHz) used with RG191 plus AS915 and...

  • Page 10: Connecting The Hardware

    Attach the two shorter antennas to the 2.4/5.5 GHz (Wi-Fi) ports. Attach the third and longer antenna to the 868 MHz/900 MHz (LoRa) port. Wi-Fi LoRa https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 11: Wi-Fi Quick Configuration

    IP address at https://192.168.1.1 Accept the self-signed security certificate in the browser. Click Advanced (Figure https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 12 Figure 6: Web interface – second screen Log on using the following default credentials: Username: sentrius Password: RG1xx Figure 7: Gateway interface login screen https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 13 Only one login session is allowed at a time. If there is another active session active, the program warns you before allowing you to take over the session (Figure Figure 9: Active session warning Click Continue to log in. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 14: Lte Connection Setup

    Auto – In auto mode, you have the option of selecting the auto DHCP method (either stateless or SLAAC). As of June 2017, IPv6 static mode is only partially supported. Please see the software release notes for current information. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 15: Advanced View

    This view is intended to support advanced users in troubleshooting their network. Figure 12: Advanced view https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 16: Wi-Fi Connection Setup

    Connect to a Wi-Fi network – click Scan to scan for nearby Wi-Fi networks. Scanning continues until you click Stop or click on one of the listed scan results (Figure 14). Figure 14: Scan function Click on the applicable scan result. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 17: Manually Adding A Profile

    The profile page shows all Wi-Fi profiles that are saved in the gateway. You can add, activate, or delete the profiles shown on this page. Click + Profile to display the Wi-Fi profile dialog (Figure 17). https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 18: Wi-Fi Advanced Page

    The Wi-Fi advanced page shows more detailed information about the Wi-Fi radio status and allows the user to configure the Quick Config AP mode password (Figure 18). Figure 18: Wi-Fi Advanced page https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 19: Lora Connection Setup

    After applying a preset, further changes can be made on the other screens. Some presets use a custom forwarder and may not be modified. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 20: Semtech Basic Station

    CUPS servers to provision the LNS certificates. Figure 22: LNS server https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 21: Certificates

    The status of the connection to the LNS is shown on the sidebar when in the LoRa view. Figure 24: LoRa view https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 22: Senet

    8.4.1 Mode The forwarder page allows configuration of the packet forwarder. The mode allows the user to change to different packet forwarders. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 23: Configuration

    At the top of the Radios page is a graphic representation of the full bandwidth range, channels, and radios. This graphic is different for gateways operating in US mode and EU mode. Figure 27: Channel plan graphic https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 24 The interface displays a warning and marks each channel in red if they overlap (Figure 30). Channel configuration is shown in Figure Figure 29: Channels window https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 25 If a 500-kHz channel is not configured, the interface displays a warning. Figure 31: US region gateways https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 26: Advanced Configuration

    The user must take care to set the appropriate credentials when restoring the saved configuration to a gateway. Figure 33: Current configuration file https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 27: Traffic

    Figure 34: LoRa traffic Clicking on a traffic row displays packet details. Figure 35: LoRa packet details https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 28: Manage The Gateway

    LoRa traffic, the time is set to the maximum of 60 minutes. When polling is stopped, the time out is set back to the saved setting. Figure 37: Change web session time out https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 29: Version Information

    93.7.1.13 (GA1) Firmware The firmware update process downloads the firmware to the gateway and then flashes it. Figure 39: Updating gateway firmware window https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 30: Save/Restore Settings

    That means security-related settings cannot be restored onto a separate gateway. Security related settings are only saved on the current gateway and can be restored on the same gateway. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 31: Remote Management

    This works much like it does with the web User Interface (UI). When the system administrator has a new firmware release to load, they will update the InternetGatewayDevice.Laird.GatewayManagement.Versions.FirmwareUpdateURL. The value is the link to download the firmware. This link always points to a fw.txt file. Once that is done, the gateway will respond with success, and download the firmware in the background.

  • Page 32: Configuration File Upload

    InternetGatewayDevice.DeviceInfo.SerialNumber Unique value assigned to each device at production InternetGatewayDevice.DeviceInfo.HardwareVersion Hardware version InternetGatewayDevice.DeviceInfo.SoftwareVersion Software version InternetGatewayDevice.DeviceInfo.MemoryStatus MemoryStatus node InternetGatewayDevice.DeviceInfo.MemoryStatus.Total Total system memory https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 33 Hardcoded Wi-Fi settings in the gateway InternetGatewayDevice.Laird.WIFIGlobalSettings.CCXFeatures Hardcoded Wi-Fi settings in the gateway InternetGatewayDevice.Laird.WIFIGlobalSettings.CertificatePat Hardcoded Wi-Fi settings in the gateway InternetGatewayDevice.Laird.WIFIGlobalSettings.DateCheck Hardcoded Wi-Fi settings in the gateway https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 34 This is the URL to the LNS server A string representing the URL InternetGatewayDevice.Laird.LORASettings.SBSLNSURL used by Basic Station. of the LNS server. https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 35 InternetGatewayDevice.Laird.GatewayManagement.Versions.Driver Driver package version InternetGatewayDevice.Laird.GatewayManagement.Versions.Supplicant Wi-Fi supplicant version InternetGatewayDevice.Laird.GatewayManagement.Versions.Build Build version InternetGatewayDevice.Laird.GatewayManagement.Versions.HardwareChipset Hardware chipset InternetGatewayDevice.Laird.GatewayManagement.Versions.Firmware Wi-Fi firmware version InternetGatewayDevice.Laird.GatewayManagement.Versions.CLI SDC CLI version https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 36 URL for the ACS to use to initiate InternetGatewayDevice.ManagementServer.ConnectionRequestURL to initiate a connection a connection with the gateway String representing InternetGatewayDevice.ManagementServer.ParameterKey the parameter key (opt.) https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 37 Only InternetGatewayDevice.WANDevice.{x}.WANConnectionDevice.{y} one Wi-Fi connection is allowed on this gateway Sub-node for each Wi-Fi InternetGatewayDevice.WANDevice.{x}.WANConnectionDevice.{y}.WANIPConnection device. Only one Wi-Fi connection is https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 38 Enables the specific Wi-Fi InternetGatewayDevice.LANDevice.{x}.WLANConfiguration.{y}.RadioEnable true, false device Enables the specific Wi-Fi Represents the SSID of InternetGatewayDevice.LANDevice.{x}.WLANConfiguration.{y}.SSID device the active Wi-Fi profile https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 39 PSK. Displays the enabled security mode. A string InternetGatewayDevice.WiFi.EndPoint.{x}.Profiles.{y}.Security.ModeEnabled These are the standard TR-181 security selected from type strings InternetGatewa https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...
  • Page 40 Data model reference to the SSID for the InternetGatewayDevice.WiFi.EndPoint.{x}.SSIDReference currently active profile Profile reference for the currently active InternetGatewayDevice.WiFi.EndPoint.{x}.ProfileReference profile InternetGatewayDevice.WiFi.EndPoint.{x}.Status Profile status InternetGatewayDevice.WiFi.EndPoint.{x}.Enable true, false https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 41: Debug

    At the bottom of the web UI is a debug pane that can be used to view system logs on the gateway. Click the arrow buttons to expand or collapse the debug pane. To start or stop debug log polling, click Auto Update Logs. Figure 44: Debug info https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 42: Factory Reset

    For the latest version of this manual, quick start guide, regulatory information and firmware updates, please see the Documentation tab the RG191+LTE page on Lairdconnect.com: https://www.lairdconnect.com/wireless-modules/lorawan- solutions/sentrius-RG191+LTE-lora-enabled-gateway-wi-fi-bluetooth-ethernet https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 43: Ip67 Rated Enclosure

    Figure 47: Side panel of the IP67 Rated Sentrius™ RG191+LTE Gateway (Current CAT6 Ethernet module Generation) Plastic gore ventilation plug https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 44: Specification

    Laird 001-0012 IP67-rated Type Dipole Connector RP-SMA 2.0 dBi (2.4–2.5 GHz), 2.0 dBi (4.9–5.875 Antenna Gain GHz) LoRa Antenna Laird 001-0011 IP67-rated (902–928 MHz) Model used with RG191+LTE Type Dipole Connector RP-SMA 2.0 dBi (863–870 MHz) used with RG186 Antenna Gain 2.0 dBi (902–928 MHz) used with RG191...

  • Page 45: Led Display Reference

    Reference Description Power Ethernet Wi-Fi User N/A (Future Use) Note: All LEDs are green. Figure 49: Six LED display (#7 from Figure https://www.lairdconnect.com/ Americas: +1-800-492-2320 © Copyright 2020 Laird Connectivity. Europe: +44-1628-858-940 All Rights Reserved Hong Kong: +852 2923 0610...

  • Page 46: Previous Generation Connector Adapter Layout

    Plastic gore ventilation plug 10.4 Cable Assemblies 10.4.1 Power Supply and Ethernet Module Figure 51: Power cable (left) and Ethernet (right) assembly components https://www.lairdconnect.com/wireless- Americas: +1-800-492-2320 modules/lorawan-solutions/sentrius- © Copyright 2020 Laird. All Rights Reserved Europe: +44-1628-858-940 RG191+LTE-lora-enabled-gateway-wi-fi-ethernet Hong Kong: +852 2923 0610...

  • Page 47: Assembly Steps

    (Figure 54). Fit the lock (vi) and o-ring (ix) onto the housing (vii) (Figure 54). Figure 54: Steps 3 and 4 https://www.lairdconnect.com/wireless- Americas: +1-800-492-2320 modules/lorawan-solutions/sentrius- © Copyright 2020 Laird. All Rights Reserved Europe: +44-1628-858-940 RG191+LTE-lora-enabled-gateway-wi-fi-ethernet Hong Kong: +852 2923 0610...

  • Page 48: Mounting Hardware

    4” hose clamps – 2 M5x1.0x10.0 mm, stainless steel screws with washers (optional) – 4 Figure 57: Wall Mount Figure 58: Wall mount dimensions https://www.lairdconnect.com/wireless- Americas: +1-800-492-2320 modules/lorawan-solutions/sentrius- © Copyright 2020 Laird. All Rights Reserved Europe: +44-1628-858-940 RG191+LTE-lora-enabled-gateway-wi-fi-ethernet Hong Kong: +852 2923 0610...

  • Page 49: Pole Mount

    Figure 60: Pole mount (pole diameter range ~34 mm – 90 Dimensions Figure 61: Pole mount dimensions https://connectivity.lairdtech.com/wireless-modules/lorawan- America: +1 919 597 7300 solutions/sentrius-RG191+LTE-lora-enabled-gateway-wi-fi-bluetooth- Europe: +46 31 420530 ethernet © Copyright 2020 Laird. All Rights Reserved Asia: +86 755 2714 1166...

  • Page 50: Fcc And Ised Canada Regulatory Statements

    Sentrius RG191+LTE User Guide ISED C ANADA EGULATORY TATEMENTS This product contains the RG191-M2, the WB50NBT from Laird and the Quectel Wireless Solutions EG91-NA Model US/FCC CANADA/IC RG191+LTE SQG-RG191NALTE 3147A-RG191NALTE contains… RG191-M2 SQG-1001 3147A-1001 WB50NBT SQG-WB50NBT 3147A-WB50NBT EG91-NA XMR201807EG91NA 10224A-2018EG91NA...

  • Page 51: Ised Radiation Exposure Statement

    être installée pour fournir une distance d'au moins 20 cm de toutes les personnes et ne doit pas fonctionner en conjonction avec toute autre antenne ou transmetteur. https://connectivity.lairdtech.com/wireless-modules/lorawan- America: +1 919 597 7300 solutions/sentrius-RG191+LTE-lora-enabled-gateway-wi-fi-bluetooth- Europe: +46 31 420530 ethernet © Copyright 2020 Laird. All Rights Reserved Asia: +86 755 2714 1166...

  • Page 52: Labels

    Sentrius RG191+LTE User Guide ABELS 12.1 RG191+LTE The RG191+LTE Figure 62: RG191+LTE Region Supported Label https://connectivity.lairdtech.com/wireless-modules/lorawan- America: +1 919 597 7300 solutions/sentrius-RG191+LTE-lora-enabled-gateway-wi-fi-bluetooth- Europe: +46 31 420530 ethernet © Copyright 2020 Laird. All Rights Reserved Asia: +86 755 2714 1166...
