T7DBG840N
T7DBG842R
USER
MANUAL
EN
User Manual
Tumble Dryer

Advertisement

loading

  Also See for AEG 7000 Series

  Related Manuals for AEG 7000 Series

  Summary of Contents for AEG 7000 Series

  • Page 1 T7DBG840N User Manual Tumble Dryer T7DBG842R USER MANUAL...
  • Page 2: Table Of Contents

    1369/2017....................... 26 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 Keep detergents away from children. • Keep children and pets away from the appliance when • the door is open. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user •...
  • Page 5 ENGLISH The appliance contains flammable gas, propane (R290), a gas with a high level of environmental compatibility. Keep fire and ignition sources away from the appliance. Be careful not to cause damage to the refrigerant circuit containing propane. WARNING: In the appliance enclosure or in the built - •...
  • Page 6: Safety Instructions

    WARNING: Never stop a tumble dryer before the end • of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. Before any maintenance operation, deactivate the • appliance and disconnect the mains plug from the socket.
  • Page 7 ENGLISH compatibility. Keep fire and ignition with a high level of environmental sources away from the appliance. Be compatibility. Keep fire and ignition careful not to cause damage to the sources away from the appliance. Be refrigerant circuit containing propane. careful not to cause damage to the refrigerant circuit containing propane.
  • Page 8: Product Description

    • Remove the door catch to prevent for the disposal of Waste Electrical children or pets from becoming and Electronic Equipment (WEEE). trapped in the drum. • Dispose of the appliance in accordance with local requirements 3. PRODUCT DESCRIPTION...
  • Page 9: Control Panel

    ENGLISH 4. CONTROL PANEL Program dial On/Off button Display Programs Start/Pause button Options 4.1 Display Symbol on the display Symbol description laundry maximum load delay start option on delay start selection (30min-20h) cycle time indication buzzer off...
  • Page 10: Programme

    Symbol on the display Symbol description child lock on laundry dryness: iron dry, cupboard dry, cupboard dry +, extra dry drain the water container indicator: clean the filter indicator: check the condenser indicator: time dry option on time programme selection (10min-2h)
  • Page 11 ENGLISH Programme Properties / Fabric mark Load Easy care fabrics for which a minimum of ironing is necessary. The drying results can be different from one type of fabric to another. Shake the 1 kg (or 5 items before putting them in the appliance. Easy Iron shirts) When the programme has ended, immediately...
  • Page 12: Options

    Options Dryness Anti-crease Refresh Time Drying Programmes Level Sport 1) Together with the programme you can set 1 or more options. 2) Set by default 3) See chapter OPTIONS: Time Drying on Wool programme 5.2 Consumption data Energy consump‐...
  • Page 13: Before First Use

    ENGLISH - ready to store - extra dry TIME DRYING RECOMMENDATION level. full drying of the small laundry > 40 6.2 Anti-crease loads up to 4 kg, well spun (>1200 rpm). Extends up to 120 minutes the anti- crease phase (30 minutes) at the end of 6.5 Time Drying on Wool the drying cycle.
  • Page 14 Drum starts to rotate. Rear drum locks After product unpacking you can feel an are automatically deactivated. unusual smell. This is normal for brand new products. If the drum still does not Appliance is built of several different rotate, please release the...
  • Page 15: Daily Use

    ENGLISH 8. DAILY USE 8.1 Preparing the laundry • Always set the programme suitable for the type of laundry. Very often the clothes after • Do not put light and dark colours washing cycle are kneaded together. and tangled altogether. •...
  • Page 16 8.2 Loading the laundry 8.5 Setting a programme CAUTION! Ensure the laundry is not trapped between the appliance door and the rubber seal. Use the programme dial to set the programme. The approximate programme duration appears on the display.
  • Page 17: Hints And Tips

    ENGLISH 8.9 Program change buttons and the program dial (this option does not lock the On/Off button). To change a program: You can activate the child lock option: 1. Push the On/Off button to turn the • before you touch the Start/Pause appliance off.
  • Page 18: Care And Cleaning

    Dryness Display symbol remaining textile fibres (simple coffee level filter is suitable). • Always keep the airflow slots at the Standard bottom of the appliance clear. dryness • Make sure there is good airflow where 6.
  • Page 19 ENGLISH CAUTION! Avoid the use of water to clean the filter. Instead throw away lint in the dustbin ( avoid dispersion of plastic fiber in water ambient). 1. Open the door. Pull the filter up. 10.2 Emptying the water container Empty the condensed water container after each drying cycle.
  • Page 20 10.3 Cleaning the condenser 4. Lower the condenser lid. Condenser flashes on If the symbol the display, inspect the condenser and its compartment. If it is dirty, clean it. Do the check not less than once a 6 months.
  • Page 21: Troubleshooting

    ENGLISH To clean you can use harder side of drum lifters. Dry the cleaned surfaces dish-washing sponge and bit of vinegar with a soft cloth. or dish soap. CAUTION! To clean the sensor: Do not use abrasive materials or steel wool to 1.
  • Page 22 Possible cause Possible cause Remedy Internal fail. No communication be‐ The programme was not finished tween electronic elements of the properly or the appliance stoped appliance. too early. Switch the appliance off and on again. If the alarm code appears again, contact the Authorised Service Centre.
  • Page 23 ENGLISH Problem Possible cause Remedy Incorrect programme selection. Select a suitable programme. The filter is clogged. Clean the filter. Dryness Level option was set to Change Dryness Level option to a higher level. iron dry . The load was too large. Do not exceed the maximum load size.
  • Page 24: Technical Data

    Problem Possible cause Remedy The load size is small. Select a time programme. The time value must be related to the load. To dry one item or a small amount of laundry we recommend The drying cycle short drying times.
  • Page 25 ENGLISH Voltage 230-240 V Frequency 50 Hz Sound power level 66 dB Necessary fuse 13 A Total power 800 W Energy efficiency class Energy consumption on the standard cotton 1,93 kWh programme with the full load. Energy consumption on the standard cotton 1,08 kWh programme with the partial load.
  • Page 26: Accessories

    13. ACCESSORIES 13.1 Stacking kit Accessory name: DK11. Available from your authorised vendor (can be attached to some types of tumble dryer) For thorough draining of the condensed water into a basin, siphon, gully, etc. After installation, the water container is drained automatically.
  • Page 27 ENGLISH Model T7DBG840N PNC916098694 T7DBG842R PNC916098988 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class Energy consumption in kWh per year, based on 160 drying cy‐ 234,7 cles of the standard cotton programme at full and partial load, and the consumption of the low-power modes.
  • Page 28 Sound power level in dB Built in appliance Y/N The information given in the chart above is compliant with the EU Commission regulation 392/2012 implementing directive 2009/125/EC. 15. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste.
  • Page 32 www.aeg.com/shop...
