Control Panel - Wave SWIFT Installation And User Manual

13) Check that the drain plug is closed 14) Fill the spa pool until the indicated
properly.
be used.
bottom of the spa. Pull the outer wall out from the top edge, all around the bottom of the spa, so
3.4. Pool cover and security
After each use, the control panel must be locked and the
pool must be coated with its top cover and it must be at-
tached to the base protector with the safety buckles.
Each safety buckles has a lock system ; closed buckle, the
latch in up position locks the buckle, the latch in down posi-
tion unlocks the buckle.
The top cover keeps the heat from the water and secures the pool.
10
3. INSTALLATION 4. USAGE

4.1. Control panel

LED Display
Heat Button
Massage Button
Temperature
Lock Button
units indicator
4.2. Functions
Once powered-up, the LED displays the current water temperature automatically.
The temperature units selector changes the temperature units from Celsius de-
grees to Fahrenheit degrees.
1 degree at once. The temperature could be set between 30°C to 40°C (86°F to
104°F).
To lock or unlock the control panel, press the Lock button and hold 3 seconds.
Lock the control panel when you are away to prevent other people come to
change your settings..
Press the massage button to activate the bubble massage system, the green
indicator light turns on. It can be turned off by pressing it again.
Note :
- The massage system will stop automatically after 30 minutes of operation. Re-activate the mas-
sage function by pressing the massage button again.
indicator light will turn off and massage indicator light turn on. If press the bubble button again, the
Temperature
Increase Button
EN
Temperature
units
selector
Temperature
Decrease Button
11
