Ruby SDB-SS 2010 Instructions Manual page 5

4. Fixing and installation
Minimal distance of installation to be respected
The apparat can be placed on volume 2 and 3 of the bathroom (see picture above).
You ensure that the installation of the apparatus respects the distances minima strictly: to
60 cm of flammable objects and 140 cm of the level of the ground.
Installation
To placed correctly the apparat,
1. For the model SDB-SS 2010, assemble the dry-towels on the support fixed at the wall
(fig1) without you support on the bottom of the heating
2. Hang the apparatus on its support (fig2). There are 3 points of fixing to the back of the
apparatus. Place the apparatus against the wall with the 2 higher points of fixing above the
support fixed at the wall. Make slide the apparatus downwards until the 2 points are fixed
on the legs of the support. Press to the bottom firmly.
