View of the Centralized Controller
Front View
N The operating lamp comes on even when only one air conditioner
N N
o o
t t
e e
N N
o o
t t
e e
connected to the centralized controller is operating.
Side View
Operating Mode Switch
N Choose the appropriate operating mode with the Operating Mode Switch
N N
o o
t t
e e
N N
o o
t t
e e
that enables the user to choose between the Cool/Auto/Heat mode.
4
E-
Operating lamp
All On button
All Off button
On/Off indicators
On/Off buttons
Index
COOL
AUTO
HEAT
