LOXONE AO Extension Manual page 2

About the product
With the Loxone AO Extension, you can easily extend your
Loxone system with four additional analogue 0-10V outputs.
Features
• 4 analogue outputs 0...10V
Installation & electrical connection
The installation of this device has to be carried out by a
qualified person. The device has to be fitted in accordance
with building regulations for electrical and fire safety. If the
device is not installed according to manufacturer's guidelines
the protection of the device may be affected.
Power Supply and Link Connection
Wire Diameter 0.25...0.8mm² / AWG23...AWG18
Exposed Wire Length 5mm / 0.2"
Push-In-Technology To make connection, insert wire; to
remove the wire, twist and pull at the
same time.
This folder is a part of the product!
For additional information, declaration of
confirmity, visit www.loxone.com/help/ao
AO
Extension
Power
Loxone
Supply
AQ1
AQ2
AQ3
AQ4
