Technical Specifications
Power Supply
14...28VDC SELV
Power Consumption
max. 1.26W
Total Power Loss
max. 435mW
Outputs
4 analogue outputs 0...10VDC
Momentary Output
max. 20mA
Continuous Output
max. 10mA
Safety Rating
IP20
Ambient Temperatures
0...55°C / 32...131°F
Humidity
95% r.H. (non condensing)
Dimensions
35.5x88x57mm /
1.4x3.46x2.24" (LxWxH)
Maintenance & Cleaning
This device is free of maintenance
and must only be cleaned with a
dry cloth.
AO Connection
Wire Diameter
0.14...0.5mm² / AWG26...AWG20
Exposed Wire Length
7mm / 0.28"
Push-In-Technology
To make connection, insert wire; to
remove the wire, twist and pull at
the same time.
No Gimmicks.
Real Smart Homes.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
AO
Extension
Part No.: 100382
Advertisement
Related Manuals for LOXONE AO Extension
Summary of Contents for LOXONE AO Extension
- Page 1 35.5x88x57mm / 1.4x3.46x2.24” (LxWxH) Maintenance & Cleaning This device is free of maintenance and must only be cleaned with a dry cloth. AO Connection Loxone Electronics GmbH Smart Home 1 Wire Diameter 0.14...0.5mm² / AWG26...AWG20 4154 Kollerschlag Austria Exposed Wire Length 7mm / 0.28”...
- Page 2 About the product With the Loxone AO Extension, you can easily extend your Loxone system with four additional analogue 0-10V outputs. Features • 4 analogue outputs 0...10V Installation & electrical connection The installation of this device has to be carried out by a qualified person.
