LOXONE Touch Nightlight Air Quick Start Manual

Technical Specifications

Power supply 5VDC via Micro USB Power supply
typ. <150mW, max. 5W
Power consumption
max. 5W
Power loss
Interfaces
Loxone Air:
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Ambient temperature -40 ... 35°C / -40 ... 91°F
Humidity
max. 95% r. H. (non condensing)
Touch points
7 touch points, capacitive
touch detection
Click feedback
Yes
Alarm clock function Alarm time adjustable on the
device, built-in alarm signal or
alarm playback via music server
Lighting
RGBW illumination through
back of device as night light
Display Time, alarm time and temperature
More datas
Safety rating
IP20
Dimensions
120x120x75mm /
4.72x4.72x2.95" (LxWxH)
This device is free of main-tenance
Maintenance & Cleaning
and may only be cleaned with a dry
cloth.
Information
Contains FCC ID: COR-ZWIR4512AC1
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired operation
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Touch
Nightlight
Air
Part No: 100340
