Technical Specifications
Power supply
4.4 ... 5.25VDC via included
micro USB power supply
Power consumption
typ. 1.3W, max. 1.3W
1.3W
Power loss
Interface
Loxone Air:
868MHz (SRD Band Europe),
915MHz (ISM Band Region 2)
max. Power 3.16mW
internal antenna
Loxone Link:
connection with up to 30
Extensions
LAN: 100Mbps, IPv4
Ambient temperature
0 ... 50°C / 32 ... 122°F
Humidity
max. 95% r.H. (non condensing)
Safety rating
IP20
Dimensions
90x90x20mm /
3.54x3.54x0.79" (LxWxH)
The device is free of
Maintenance and cleaning
maintenance and may only
be cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Miniserver
Go
Part No: 100139
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LOXONE Miniserver Go
Summary of Contents for LOXONE Miniserver Go
- Page 1 0 ... 50°C / 32 ... 122°F Humidity max. 95% r.H. (non condensing) Safety rating IP20 Dimensions 90x90x20mm / Loxone Electronics GmbH 3.54x3.54x0.79” (LxWxH) Smart Home 1 4154 Kollerschlag The device is free of Maintenance and cleaning Part No: 100139...
- Page 2 About the product Loxone Link Connection The Miniserver Go is a device for the automatic control and management of home automation and similar non safety 0.2 ... 1.5 mm² / AWG24 ... 16 Wire cross-section critical applications. The Loxone Miniserver Go has a fully integrated Air Base Extension and is perfect for retrofitting 8mm / 0.31”...
