Technical Specifications
Power Supply
6...30VDC PELV or
2x 1.5V AAA-battery
Power Consumption
typ. 87mW, max. 119mW
max. 119mW
Total Power Loss
Battery Lifetime
approx. 2 years
IP30
Safety Rating
Ambient Temperature
-20...70°C / -4...158°F
PELV Powered
Ambient Temperature
-20...54°C / -4...129°F
Battery Powered
95% r.H. (non condensing)
Humidity
868MHz (SRD Band Europe),
Radio Frequency
915MHz (ISM Band Region 2)
max. Power 3.16mW
Dimensions
90x90x16mm /
3.54x3.54x0.63" (LxWxH)
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Touch
Pure
Air
Part No: 100399 (White)
Part No: 100400 (Anthracite)
