OUTLINE DRAWINGS
4 cylinders
519
115
158
232
202
15
NTZ215
NTZ271
8
ø 352
Oil equalisation
3/8" (VE version only)
Threaded oil
sight glass
Mounting hole for PTC
crankcase heater
15°
205
246
Rotolock connections size
Suction
Discharge
1"3/4
1"1/4
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
233
125
99
Silent block
246
15°
Pipe sizing
Suction
Discharge
1"1/8"
RECIPROCATING COMPRESSORS
Schrader
1/4"
96
H M12-50
HM12-50
Rotolock valve
Suction
3/4"
V02
95
30
19
Discharge
V04
