Replacing the battery

The battery illuminates the bubble level. It should be replaced whenever the illumination
becomes inadequate.
1. If required, rotate the tilt lock lever to access the battery cover (Figure 6).
2. Use a coin or flat-blade screwdriver to unscrew the battery cover.
3. Carefully pull the battery out of its compartment using the ribbon.
tilt lock lever
button battery
battery cover
Figure 5 Adjusting the pan and tilt lock levers
Figure 6 Replacing the battery
