Main Frame Assembly - Pride Mobility Quantum 1650 Manual

Quantum Jazzy 1100 ™ 1650
REF # PART #
A1 — A5 FRMASMB6254
A1 DWR1650E004
A2 DWR1122D016
A3 SCRASBH1056
A4 VELLOOP1002
A5 PINCLEV1022
B1 — B2 FRMASMB6638
B1 SCRASBH1004
B2 DWR1650B028
*C1 DECSERN1032
Notes :
Standard Main Frame Assembly for 2-batteries. 4-batteries are an option for the Quantum 1650.
*C1 Decal is not available for replacement.
Rev. H/042406
DESCRIPTION
FRAME,ASSY,MAIN,JAZZY1650
FRAME,WELDMENT,MAIN,E-1650-004
BUMPER,SKID PLATE,PLASTIC,JAZZY1122,D-1122-016
SCREW,BHSCS,BLACK ZINC,5/16-18 X 2.00"
FASTENER,1"W X 1 1/2"L,REUSABLE, LOOP
QUICK RELEASE PIN,SELF LOCKING,1/4" X 1.50" GRIP
LENGTH,W/PLASTIC "T" HANDLE
BATTERY,ASSY,SPACER,JAZZY1650,2 BATTERY SYSTEM
SCREW,BHSCS,BLACK ZINC,1/4-20 X 0.875",GRADE 8
BATTERY SPACER,NYLON,B-1650-028
DECAL,SERIAL NUMBER,4" X 6",BARCODE,W/PRIDE LOGO
www.pridemobility.com
I. Main Frame Assembly — 2-Battery
11i
QTY MSRP (AU$)
1 2259.82
1 N/A
1 16.06
2 5.36
6 5.36
4 10.72
1 240.98
4 5.36
2 123.16
1 6
Page 5
