Quantum 1650
™
AUS
Pride Mobility Products
ACN# 088 609 661

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum 1650 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pride Mobility Quantum 1650

Summary of Contents for Pride Mobility Quantum 1650

  • Page 1 Quantum 1650 ™ Pride Mobility Products ACN# 088 609 661...
  • Page 2 Your new Pride Illustrated Parts Breakdown (IPB) Manual has been compiled from the latest product information available at the time of publication. Pride Mobility Products reserves the right to make changes and updates to this manual and to the product(s) it represents. Any changes, updates, or improvements to the product(s) may result in slight differences between this manual and the product you purchased.

  • Page 3: Table Of Contents

    Jazzy 1100 Quantum ™ 1650 Table Of Contents SECTION I. Main Frame Assembly ....................................4 2-Battery ....................................... 4 4-Battery ....................................... 6 SECTION II. Motor Assembly......................................8 SECTION III. Freewheel Assembly ....................................10 SECTION IV. Anti-tip Assembly ...................................... 12 SECTION V. Articulating Beam Assembly ..................................
  • Page 4 I. Main Frame Assembly — 2-Battery Quantum Jazzy 1100 ™ 1650 Standard Main Frame Assembly for 2-batteries. 4-batteries are an option for the Quantum 1650. *Note: If an item has no callout, it is being shown for assembly purposes. Page 4 www.pridemobility.com Rev. H/042406...

  • Page 5: Main Frame Assembly

    SCREW,BHSCS,BLACK ZINC,1/4-20 X 0.875",GRADE 8 5.36 DWR1650B028 BATTERY SPACER,NYLON,B-1650-028 123.16 DECSERN1032 DECAL,SERIAL NUMBER,4" X 6",BARCODE,W/PRIDE LOGO Notes : Standard Main Frame Assembly for 2-batteries. 4-batteries are an option for the Quantum 1650. Decal is not available for replacement. Rev. H/042406 www.pridemobility.com Page 5...
  • Page 6 I. Main Frame Assembly — 4-Battery Quantum Jazzy 1100 ™ 1650 Main Frame Assembly for the 4-battery option. *Note: If an item has no callout, it is being shown for assembly purposes. Page 6 www.pridemobility.com Rev. H/042406...
  • Page 7 Jazzy 1100 Quantum ™ 1650 I. Main Frame Assembly — 4-Battery REF # PART # DESCRIPTION MSRP (AU$) A1 — A5 FRMASMB6254 FRAME,ASSY,MAIN,JAZZY1650 2259.82 DWR1650E004 FRAME,WELDMENT,MAIN,E-1650-004 DWR1122D016 BUMPER,SKID PLATE,PLASTIC,JAZZY1122,D-1122-016 16.06 SCRASBH1056 SCREW,BHSCS,BLACK ZINC,5/16-18 X 2.00" 5.36 VELLOOP1002 FASTENER,1"W X 1 1/2"L,REUSABLE, LOOP 5.36 PINCLEV1022 QUICK RELEASE PIN,SELF LOCKING,1/4"...
  • Page 8 II. Motor Assembly Quantum Jazzy 1100 ™ 1650 A1a/A1b *Note: Right side shown. If an item has no callout, it is being shown for assembly purposes. Page 8 www.pridemobility.com Rev. H/042406...

  • Page 9: Motor Assembly

    Jazzy 1100 Quantum ™ 1650 II. Motor Assembly REF # PART # DESCRIPTION MSRP (AU$) A1 — B1 DRVASMB1588 MOTOR,ASSY,DRIVE,24 VOLT,INLINE,W/FREEWHEEL RELEASE 3716.38 LEVER,PAIR A1a — B1 DRVASMB1587 MOTOR,ASSY,DRIVE,24 VOLT,INLINE,W/FREEWHEEL RELEASE 1858.18 LEVER,RIGHT A1b — B1 DRVASMB1586 MOTOR,ASSY,DRIVE,24 VOLT,INLINE,W/FREEWHEEL RELEASE 1858.18 LEVER,LEFT *A1a...
  • Page 10 III. Freewheel Assembly Quantum Jazzy 1100 ™ 1650 *Note: Right side shown. If an item has no callout, it is being shown for assembly purposes. Page 10 www.pridemobility.com Rev. H/042406...

  • Page 11: Freewheel Assembly

    Jazzy 1100 Quantum ™ 1650 III. Freewheel Assembly REF # PART # DESCRIPTION MSRP (AU$) B1 — B9 FRMASMB6314 FREEWHEEL,ASSY,LEVER,JAZZY1650 74.98 DWR1650B016 FREEWHEEL,T-HANDLE,B-1650-016 DWR1650B013 BOLT,1/4-20 THREAD BOTH ENDS X 3.50" LG,FREEWHEEL ARM,B-1650- 5.36 DWR1650B015 FREEWHEEL,ARM,BENT,B-1650-015 21.42 BLTASHL1006 BOLT, SHOULDER,1/4"X 1/2" 5.36 WASSAE1003 WASHER,FLAT,BLACK ZINC,1/4,0.281"...
  • Page 12 IV. Anti-tip Assembly Quantum Jazzy 1100 ™ 1650 A1a/A1b B1a/B1b *Note: Right side shown. If an item has no callout, it is being shown for assembly purposes. Page 12 www.pridemobility.com Rev. H/042406...

  • Page 13: Anti-Tip Assembly

    Jazzy 1100 Quantum ™ 1650 IV. Anti-tip Assembly REF # PART # DESCRIPTION MSRP (AU$) A1a — D5 FRMASMB6310 ANTI-TIP,ASSY,MAIN,CAM ADJUSTABLE,W/STRUT & 305.24 WHEEL,JAZZY1650,RIGHT A1b — D5 FRMASMB6309 ANTI-TIP,ASSY,MAIN,CAM ADJUSTABLE,W/STRUT & 305.24 WHEEL,JAZZY1650,LEFT A1a — C2 FRMASMB6312 BRACKET,ASSY,ANTI-TIP,W/FORK/WHEEL/CAM,JAZZY1650,RIGHT 262.4 A1b — C2 FRMASMB6311 BRACKET,ASSY,ANTI-TIP,W/FORK/WHEEL/CAM,JAZZY1650,LEFT 262.4...
  • Page 14 V. Articulating Beam Assembly Quantum Jazzy 1100 ™ 1650 B1 — C2 *Note: If an item has no callout, it is being shown for assembly purposes. Page 14 www.pridemobility.com Rev. H/042406...

  • Page 15: Articulating Beam Assembly

    Jazzy 1100 Quantum ™ 1650 V. Articulating Beam Assembly REF # PART # DESCRIPTION MSRP (AU$) A1 — E3 FRMASMB6255 ARTICULATING BEAM,ASSY,ANGLED,MAIN, W/9'' FLAT FREE 1751.08 CASTERS, JAZZY1650 A1 — A16 FRMASMB6256 ARTICULATING BEAM,ASSY,ANGLED,JAZZY1650 498.02 DWR1650E006 ARTICULATING BEAM,WELDMENT,BLACK,ANGLED,E-1650-006 321.3 DWR1650C020 ARTICULATING BEAM MOUNTING BRACKET WELDMENT,C-1650-020 133.88 SCRHHCS1183...
  • Page 16 VI. Electronics Assembly — 2-Battery Quantum Jazzy 1100 ™ 1650 R(–) R(+) L(–) L(+) Joystick *Note: If an item has no callout, it is being shown for assembly purposes. Page 16 www.pridemobility.com Rev. H/042406...

  • Page 17: Electronics Assembly

    Jazzy 1100 Quantum ™ 1650 VI. Electronics Assembly — 2-Battery REF # PART # DESCRIPTION MSRP (AU$) A1 — A16 ELEASMB3619 ELECTRONIC,ASSY,REMOTE PLUS,100 AMP,JAZZY1650,OFFBOARD 1226.3 CHARGER,2 BATTERY SYSTEM DWR1650H001 ELECTRONIC,HARNESS,BATTERY CABLE, REMOTE PLUS, 4 358.78 CONNECTIONS,H-1650-001 DWR1650B022 CIRCUIT BREAKER MOUNTING BRACKET,B-1650-022 21.42 ELECBRK1012 ELECTRONIC,CIRCUIT BREAKER,80 AMP,AUTO-RESET...
  • Page 18 VI. Electronics Assembly — 4-Battery Quantum Jazzy 1100 ™ 1650 RR(–) RR(+) RF(–) RF(+) LR(+) LR(–) LF(–) LF(+) Joystick *Note: If an item has no callout, it is being shown for assembly purposes. Page 18 www.pridemobility.com Rev. H/042406...
  • Page 19 Jazzy 1100 Quantum ™ 1650 VI. Electronics Assembly — 4-Battery REF # PART # DESCRIPTION MSRP (AU$) A1 — A16 ELEASMB3563 ELECTRONIC,ASSY,REMOTE PLUS,100 AMP,JAZZY1650,OFFBOARD 1601.14 CHARGER,4 BATTERY SYSTEM DWR1650H001 ELECTRONIC,HARNESS,BATTERY CABLE, REMOTE PLUS, 4 358.78 CONNECTIONS,H-1650-001 DWR1650B022 CIRCUIT BREAKER MOUNTING BRACKET,B-1650-022 21.42 ELECBRK1012 ELECTRONIC,CIRCUIT BREAKER,80 AMP,AUTO-RESET...

  • Page 20: Controller Assembly

    VII. Controller Assembly Quantum Jazzy 1100 ™ 1650 Remote Plus To Power Module Remote Plus Microdrive Page 20 www.pridemobility.com Rev. H/042406...
  • Page 21 Jazzy 1100 Quantum ™ 1650 VII. Controller Assembly REF # PART # DESCRIPTION MSRP (AU$) CTLDC1368 CONTROLLER,JOYSTICK MODULE, REMOTE PLUS,3 KEY 2238.4 W/PROFILES,FLYING LEAD,(P&G D50524) B1 — B2 FRMASMB2066 FIXED INLINE JOYSTICK MOUNT,ASSY,REMOTE PLUS 53.56 DWR1200C103 MOUNTING BRACKET,JOYSTICK WELDMENT,REMOTE PLUS,INLINE,C- 42.84 1200-103 SCRPPH1006...
  • Page 22 VIII. Footrest Assembly — Standard Footplate Quantum Jazzy 1100 ™ 1650 *Note: If an item has no callout, it is being shown for assembly purposes. Page 22 www.pridemobility.com Rev. H/042406...

  • Page 23: Footrest Assembly

    Jazzy 1100 Quantum ™ 1650 VIII. Footrest Assembly — Standard Footplate REF # PART # DESCRIPTION MSRP (AU$) A1 — B9 FRMASMB9496 FOOT PLATFORM,ASSY,17W X 13''D,W/MOUNTING 2516.86 BRACKETS,JAZZY1650 FRMASMB9444 FOOT PLATFORM,ASSY,HD,17"W,13"D,W/MAT & HARDWARE,E-1650- 2184.84 SCRHHCS1230 SCREW,HHCS,BLACK,ZINC,1/4-20 X 1.5",GRADE 8 5.36 NUTNJAM1014 NUT,NYLOCK JAM,BLACK ZINC,1/4-20 5.36...
  • Page 24 VIII. Footrest Assembly — Option Footplate Quantum Jazzy 1100 ™ 1650 *Note: If an item has no callout, it is being shown for assembly purposes. Page 24 www.pridemobility.com Rev. H/042406...
  • Page 25 Jazzy 1100 Quantum ™ 1650 VIII. Footrest Assembly — Option Footplate REF # PART # DESCRIPTION MSRP (AU$) A1 — C1 FRMASMB6390 FOOT PLATFORM,ASSY,17W X 16''D,W/MOUNTING 2115.22 BRACKETS,JAZZY1650 SCRHHCS1230 SCREW,HHCS,BLACK,ZINC,1/4-20 X 1.5",GRADE 8 5.36 NUTNJAM1014 NUT,NYLOCK JAM,BLACK ZINC,1/4-20 5.36 B1 — B9 FRMASMB6389 FOOT PLATFORM MOUNTING BRACKET,ASSY,JAZZY1650 278.46...
  • Page 26 IX. Wheel Assembly — Pneumatic Quantum Jazzy 1100 ™ 1650 REF # PART # DESCRIPTION MSRP (AU$) A1 — B5 WHLASMB1551 WHEEL,ASSY,DRIVE, PNEUMATIC,4.00 X 8",HONEYCOMB,C-168,3- 348.08 PIECE RIM W/ FORGED STEEL HUB,19MM BORE & DOUBLE KEYWAY,E-1650-007 TIRPNEU1017 TIRE,PNEUMATIC,400-8X16'',C-168-7 112.46 TUBSTND1017 TUBE,3.50/4.00-8,ANGLED VALVE W/CAP 32.14 DWR7700A010...

  • Page 27: Wheel Assembly

    Jazzy 1100 Quantum ™ 1650 IX. Wheel Assembly — Flat-free REF # PART # DESCRIPTION MSRP (AU$) A1 — B5 WHLASMB1558 WHEEL,ASSY,FLAT FREE,4.00 X 8",DRIVE WHEEL,HONEYCOMB,C- 551.56 168,3-PIECE RIM W/19MM KEYWAY,HIGH DENSITY FOAM,E-1000-174 TIRSOLI1045 TIRE,FLAT FREE INSERT,400-8 X 16,HIGH DENSITY FOAM,C-168 224.92 B1 —...
  • Page 28 X. Shroud Assembly Quantum Jazzy 1100 ™ 1650 A1a/A1b/A1c/A1d/A1e/A1f/A1g Page 28 www.pridemobility.com Rev. H/042406...

  • Page 29: Shroud Assembly

    Jazzy 1100 Quantum ™ 1650 X. Shroud Assembly REF # PART # DESCRIPTION MSRP (AU$) A1a — A3 SHDASMB3930 SHROUD,ASSY,GREEN,JAZZY1650 626.54 SHDPNTD2316 SHROUD,PAINTED,GREEN,JAZZY1650 621.18 A1b — A3 SHDASMB3931 SHROUD,ASSY,RED,JAZZY1650 626.54 SHDPNTD2317 SHROUD,PAINTED,RED,JAZZY1650 915.7 A1c — A3 SHDASMB3932 SHROUD,ASSY,VIPER BLUE,JAZZY1650 626.54 SHDPNTD2318 SHROUD,PAINTED,VIPER BLUE,JAZZY1650 621.18...

  • Page 30: Charger Assembly

    XI. Charger Assembly Quantum Jazzy 1100 ™ 1650 REF # PART # DESCRIPTION MSRP (AU$) ELE110V1041 CHARGER,OFFBOARD, LOW INHIBIT,110V, 8AMP,H-1010- 1006.74 054,(LESTER:18330-48) Page 30 www.pridemobility.com Rev. H/042406...

  • Page 31: Owner's And Decal Packages

    DWR1234L008 DECAL,ICON,EXTENSION CORD/GROUNDING PRONG,L-1234-008 5.36 *N/A DWR1234L011 DECAL,ICON,BATTERY CORROSIVE CHEMICALS WARNING,L-1234- 5.36 *N/A DWR1234L012 DECAL,ICON,1.5",READ OWNERS MANUAL,L-1234-012 5.36 *N/A DWR1234L075 DECAL,NAME,QUANTUM 1650, SIDE,L-1234-075 5.36 *N/A DWR1234L076 DECAL,NAME,QUANTUM1650,REAR,L-1234-076 5.36 *N/A DWR1234L090 DECAL,ICON,BATTERY CONNECTION,4 BATTERIES,JAZZY1650,L- 5.36 1234-090 *N/A DWR1234L101 DECAL,ICON,BATTERY CONNECTION,2 BATTERIES,JAZZY1650,L- 5.36...
  • Page 32 A. Electrical System Diagram — 2-Battery Quantum Jazzy 1100 ™ 1650 RIGHT MOTOR TO LEFT (–) Page 32 www.pridemobility.com Rev. H/042406...

  • Page 33: Electrical System Diagram

    Jazzy 1100 Quantum ™ 1650 A. Electrical System Diagram — 4-Battery TO RIGHT FRONT (–) Rev. H/042406 www.pridemobility.com Page 33...
  • Page 34 St. Catharines, Ontario L2R 6P7 Canada Pride Mobility Products Ltd. Unit 106, Heyford Park Camp Road Upper Heyford, Oxfordshire OX25 5HA Pride Mobility Products Australia Pty. Ltd. 21 Healey Road Dandenong, 3175 Victoria, Australia Pride Mobility Products Italia S.r.l. Via del Progresso - ang. Via del Lavoro Loc.
