- Page 1 RGB WIRELESS TKL MECHANICAL GAMING KEYBOARD INSTRUCTION MANUAL ADXWMK0520...
-
Page 2: Table Of Contents
Contents Safety Warnings ..............3 Wired Connect ..............7 Unpacking ................5 Function Keys ..............8 System Requirements ............5 Backlight Effect ..............9 Product Overview ..............6 Customising the Backlight Effect ........10 Charging the Battery ............7 Specifications ..............11 Wireless Connect ...............7 Hints and Tips..............12... -
Page 3: Safety Warnings
Safety Warnings Temperature • Avoid extreme degrees of temperature, either hot or cold. Place the unit well away from heat sources such as radiators or gas / • Read all the instructions carefully before using the unit and keep electric fires. them for future reference. - Page 4 • Do not leave a fully charged battery connected to a charger, since • Do not attempt to open the product or replace the battery. It is overcharging may shorten its lifetime. built-in and not changeable. Use of other batteries may present a risk of fire or explosion and the warranty will be terminated.
-
Page 5: Unpacking
Unpacking Thank you for purchasing your new Remove all items from the packaging. Retain the product. packaging. If you dispose of it please do so according to We recommend that you spend some time reading local regulations. this instruction manual in order that you fully The following items are included: understand all the operational features it offers. -
Page 6: Product Overview
Product Overview Top View Bottom View 1. Battery Indicators 4. Brightness ON/OFF 1. Charging Mode 3. USB Dongle Storage 2. Light effect 5. Volume Control 2. USB Type C Socket 3. Wired / Wireless Switch... -
Page 7: Charging The Battery
Wireless Connect Charging the Battery 1. Press the button until the LED is off. When using the unit for the first time, charge it fully first. 2. Plug the Dongle directly into your computer’s USB 1. Connect the USB type C cable to the keyboard. port. -
Page 8: Function Keys
Function Keys To access these functions, press the FN Key and the desired key together. Start the default Media Player programme Decrease the Volume Increase the Volume Start the default Web browser and load the Mute sound Home Web page Start the default e-mail programme Stop playback Lock Keyboard... -
Page 9: Backlight Effect
Backlight Effect To access these functions, press the Fn Key and the desired key together. Adjust the backlight flashing sequence level. Switch the backlight on/off. Select different backlight effects. (5 modes / 1 customised mode) Adjust the backlight brightness. Spacebar Change the backlight colour. -
Page 10: Customising The Backlight Effect
Customising the Backlight Effect You may customise the backlight for each keypress. 1. Press Fn + repeatedly to select customise backlight mode. Keypress WASD and will light up as the first time. 2. Press and hold Fn + to enter backlight setting mode. CAPS and WIN keypresses will start flashing. -
Page 11: Specifications
Specifications Keyboard Batteries Model ADXWMK0520 Model ARS3034120 Rated Input DC 5V 500mA Battery Type DC 3.7V 1000mA Wireless Frequency Battery Rating 2.4GHz 3.7V 1000mAh 3.7Wh Operating Range < 8m (open space) Number of Battery Frequency Band(s) Designation Code 2406 – 2470 MHz 1ICP4/35/51-2 Max. -
Page 12: Hints And Tips
Hints and Tips • Restart the computer. • Recharge the battery if the keyboard no longer reacts to input. • Make sure the USB plug is fully plugged into a USB port and the computer is on or try to use a different USB port. •... - Page 13 Notes for battery disposal Windows is a registered trademark of Microsoft Corporation in the The batteries used with this product chemicals that United States and other countries. contain are harmful to the environment. To preserve our environment, dispose of used batteries All trademarks are the property of their respective owners and all according to your local laws or regulations.
- Page 14 DSG Retail Ltd. (co. no. 504877) 1 Portal Way, London, W3 6RS, UK EU Representative DSG Retail Ireland Ltd (259460) 3rd Floor Office Suite Omni Park SC, Santry, Dublin 9, Republic of Ireland IB-ADXWMK0520-200915V1...
