AQUAWORX MARC OPERATING INSTRUCTIONS
VI. Using the SD Card
NOTE: It is recommended that a SD card with SD card
adapter be used with the the MARC 2. The SD card must
not exceed 1 GB of storage in order to operate properly.
1. Insert the SD card into the designated slot on the
MARC.
2. Scroll through the MARC menus to the SD Card
Settings menu, until the screen says "Write Events."
3. ENTER = "Y" to capture events to SD card,
ENTER = "N" to skip.
NOTE: The MARC will show the events being
transferred to the SD card.
4. Once the data transfer is complete, the SD card can be
removed and placed in a card reader connected to a PC.
5. On the user's PC, locate the designated drive for
the card reader.
6. Click on the file to identify the SD card events file
(.evt) and settings file (.set).
7. The file can be opened using a spreadsheet or
text editing program.
NOTE: Each event and settings file is saved by IPC Panel
serial number, allowing the user to save the data from
multiple IPC Panels on a single SD card.
Section H.
Login Menu
14
Login
All
0000
Simplex
0000
Duplex
0000
Advanced / SF
Admin
0000
Contact Infiltrator Water Technologies 1-800-221-4436 for additional technical and product information.
SD Card Reader
NOTE: It is no longer necessary to login to access the
operating menus on the MARC.
The login menus are not necessary for normal set-up
or operation conditions.
When changing the set-up on a panel to operate more
advanced settings, it may be necessary to login under
the Admin Menu.
Contact Infiltrator Systems at 1-800-221-4436 for
more information.
