Infiltrator AQUAworx IPC Panel Installation Manual page 11

AQUAWORX MARC OPERATING INSTRUCTIONS
Section C.
MANUAL RUN PUMP "A": Allows the user to manually
operate the pump. The LCD screen details how long the
pump runs and the real-time liquid level in the tank. User
may toggle between pumping and stopped by pressing
the Enter button.
Manual Run
Pump "A" or "B"
Section D.
ACTIVATE SETTINGS: Allows the user to actuate
or upload the controller settings to the IPC Panel.
Activate Settings
NOTE: Once panel is set to Activate mode, formally
named Auto, it will return to the Status menu.
Contact Infiltrator Water Technologies 1-800-221-4436 for additional technical and product information.
Time State Level
000:12 MRun 00.0
Waiting/Pumping/Idle 001:30
Level 03.6
MANUAL RUN PUMP "B" (Duplex only): Allows the
user to manually operate a second pump. For duplex,
the pumping function will alternate between Pump A and
Pump B with each cycle of the Enter button. The screen
display for Manual "A" and Manual "B" are similar, as
follows:
Time - Counter in that event (state)
State - MRun or MStop
Activates setting and starts cycle
Goes to view status screen
IMPORTANT:
ACTIVATE must be selected after
all SETTINGS changes for the new settings
to be saved to the processor.
11
