Infiltrator AQUAworx IPC Panel Installation Manual page 10

AQUAWORX MARC OPERATING INSTRUCTIONS
Section A.
STATUS: This is a read-only set of sub-menus that allow
the user to view the IPC Panel status in real-time and
program functions as it runs through the programmed
300 AQUAWORX HUI
R1.3.2.C (c) 2012 LIPS
Section B.
EVENTS: A read-only set of sub-menus that allows the
user to view the events logged into the system (up to
4,000 events). The LCD screen details the date, time,
liquid level, event code and event count number.
10
Software version
View Status A
Time State Level
000:00 Waiting 00.0
Run Time = 00000:00:03
Doses = 00000 V = 00000
06-10-03 11:53:44
0012 Event
SW = DLL3.00 V1.0.4.d
ID =04-10-2012
AQUAWORX HUZ R1.3.2.2
by Infiltrator
Contact Infiltrator Water Technologies 1-800-221-4436 for additional technical and product information.
parameters. The IPC Panel identification number and
software version can be found in this menu.
NOTE: Status "B" is an available menu option on Duplex
panels.
Time - min / sec
State - Pumping, Waiting, Idle
Level - Inches above bottom of bell
Run Time (hr / min / sec)
Doses - Cycle counter - normal dose
V - Cycle counter - veto dose
Date and time
Number of events
Software identification version and revision
IPC Panel identification number
Time of Event
Date of
Event
00-00 12:30:14 0012
Man Off
Event
Type
Event
Number
00.0
Level at
Time of Event
