AQUAWORX MARC OPERATING INSTRUCTIONS
Section E.
PUMP "A" SETTINGS: Allows the user to set all pump
run parameters. Note: Pump "B" settings allow the user
to set parameters for a second pump (only for use on a
Duplex panel or sand filter).
Pump A Settings
Veto Dose: The Veto function is simply a separate level
that instructs the pump to run a different timing sequence
and is intended to prevent pump tank overflows. The veto
level is typically set above the high level alarm. When liq-
uid reaches the veto level, the veto pump cycle times are
initiated. The veto pump cycle times will remain in effect
until the liquid level falls below the veto level. It the veto
level is set above the alarm level, the alarm remains on.
The alarm will not de-activate until it is manually silenced
or the liquid level drops below the alarm level.
12
Pump On Time
001:00*
Pump Off Time
060:00
Veto On Time
002:30
Veto Off Time
030:00
High Level
20.0
Veto Level
19.0
Start Level
001.0
Zero Bias
07
Auto Clear
02 Doses
Contact Infiltrator Water Technologies 1-800-221-4436 for additional technical and product information.
* All values shown are the factory setting.
Standard dose pump on time
Pump On Time (minutes, seconds)
Standard dose pump off time
Pump Off Time (minutes, seconds)
High level veto dose on time (see below)
Dose On Time (minutes, seconds)
High level veto dose off time
Dose Off Time (minutes, seconds)
High level alarm setting (inches)
Veto level setting (inches)
Standard dose level setting (inches)
Calibration of transducer to IPC Panel. The Z-Bias number
is located on the pressure transducer bell and should be
recorded during transducer installation
Additional doses or time required to clear the bottom of
the bell if the liquid level is below the start level
NOTE: If local regulation will not permit the use of an
override function, then set the veto level to the same
level as the high level alarm, and set the veto on and off
times times to establish the veto doses as a counter of
the number of doses completed above the alarm level.
