Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
12 IN. WOOD LATHE
TABLE EXTENSION
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 34027EX
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Related Manuals for Wen 34027EX
Summary of Contents for Wen 34027EX
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
- Page 2 TECHNICAL DATA 34027EX Model Number: 23.5 inches Length of Extension: 41.5 inches Length of Lathe w/ Extension: 23.5 x 8 x 7 in. Dimensions: 17.5 lbs. Weight: Compatible with the WEN 12-Inch Variable Speed Wood Lathes (models 3427 & 34027)
- Page 3 ASSEMBLY INSTALLING BED EXTENSION 1. Fit the bed extension (3) to the bed using four socket head screws and four flat washers. 2. Remove the end stop screw (2) from the bed and as- semble it onto the bed extension. 3.
- Page 4 THANKS FOR REMEMBERING...
