Operation
5.2

Load on the pallet

1. Use the support roll to place the
VTK-V on the pallet. Move the VTK-V
carefully to the load.
4. Tilt the VTK-V towards yourself and
pull it so the support roll is on the edge
of the pallet. The wheels have to
extend over the edge of the pallet.
7. The VTK-V can now be moved away.
5110.0015
2. Bring the stop and the bottom plate
in position by placing the VTK-V in the
upright position.
5. Tilt the VTK-V further on until it
stands on its wheels.
V2
3. Engage the lever up to the stop
clockwise, so the load is getting
clamped.
6. At place of destination, bring the
VTK-V carefully in the upright position.
Rotate the lever counterclockwise to
release the load.
