Operation
5.2

Load on the pallet

1. Use the support roll to place the
VTK-V on the pallet. Move the VTK-V
carefully to the load.
4. Tilt the VTK-V towards yourself
and pull it so the support roll is on the
edge of the pallet. The wheels have
to extend over the edge of the pallet.
7. The VTK-V can now be moved
away.
51100015
2. Bring the stop and the bottom plate
in position by placing the VTK-V in
the upright position.
5. Tilt the VTK-V further on until it
stands on its wheels.
14 / 17
3. Engage the lever up to the stop
clockwise, so the load is getting
clamped.
6. At place of destination, bring the
VTK-V carefully in the upright
position. Rotate the lever
counterclockwise to release the load.
GB
