Page 1: Vacuum Cleaner
This manual is made with 100% recycled paper. ✻ Before operating this unit, please read the instructions carefully. ✻ For indoor use only. imagine Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register... -
Page 2: Important Safety Instructions
Safety information IMPORTANT SAFETY INSTRUCTIONS Thank you for purchasing a Samsung vacuum cleaner. When using an electrical appliance, basic precautions should always be followed, including the following : PLEASE READ ALL WARNINGS AND INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. WARNING : To reduce the risk of fi re, electric shock, or injury. -
Page 3: Save These Instructions
Safety information • Avoid picking up hard, sharp objects with the cleaner. They may damage the cleaner. • Always turn off this appliance before connecting or disconnecting the hose, removing the bottom plate for maintenance. • Use only on dry, indoor surfaces, never change the plug in any way. •... - Page 4 Safety information SAFETY INFORMATION • Before operating the appliance, please read this manual thoroughly and WARNING retain it for your reference. • Because these following operating instructions cover various models, WARNING the characteristics of your vacuum cleaner may differ slightly from those described in this manual.
-
Page 5: Table Of Contents
Contents ASSEMBLING THE CLEANER OPERATING THE CLEANER MAINTENANCE TROUBLESHOOTING 06 Product View 07 Attach Handle To Vacuum 07 Attach Dust Bin To Vacuum 07 Attach Vacuum Hose and Tools 08 Power Switch 08 Handle Positions 08 Height Adjustment 08 Transporting Cleaner 09 Special on-board tools 09 Power Cord Storage 10 Empty Dust Bin... -
Page 6: Assembling The Cleaner
Assembling the cleaner PRODUCT VIEW Handle *Option Mini Turbo Brush Mini Turbo Brush (Select Models Only) (Select Models Only) Carrying Handle Grille Cyclone Dust Bin Post-Motor Filter Post-Motor Filter (Post-Motor Filter (Post-Motor Filter is located behind the door.) the door.) Powerfoot Do not plug in your vacuum cleaner until you are familiar with all instructions CAUTION... -
Page 7: Attach Handle To Vacuum
Assembling the cleaner ATTACH HANDLE TO VACUUM Stand the vacuum upright and slide the base of the handle fi rmly into the grooves at the top of the vacuum body. Check to be sure the handle is fi tted to the vacuum body. -
Page 8: Operating The Cleaner
Operating the cleaner POWER SWITCH The Power Switch is located on the side of the vacuum. Push the rocker switch “ON” to vacuum, and “OFF” when cleaning is complete. HANDLE POSITIONS Press the handle release pedal, located on the lower left side of the vacuum, with your foot to place your vacuum into one of three cleaning positions. -
Page 9: Special On-Board Tools
Operating the cleaner SPECIAL ON-BOARD TOOLS Your vacuum is not only a powerful carpet and rug cleaner, it’s also a versatile above fl oor vacuum cleaner when you select one of the special tools. Raise Handle to Upright Position. Grasp the end of the Hose Wand and lift Hose Wand to separate from the Hose Wand Base. -
Page 10: Maintenance
Maintenance To maintain maximum cleaning performance, the following maintenance steps must be performed: Empty the Dust Bin when the dirt reaches the “MAX” line on the side. Cleaning the Grille Cyclone when the Dust Bin become clogged. Check the Pre-Motor Filter at least once a month and clean or replace as needed. -
Page 11: Cleaning The Pre-Motor Fi Lter
Maintenance CLEANING THE PRE-MOTOR FILTER Sponge Filter Micro Filter Unplug the Vacuum Cleaner from electrical outlet. The Pre-Motor Filter(Sponge Filter, Micro Filter) protects the motor from dirt particles. It is located underneath the Dust Bin. If the Pre-Motor Filter becomes dirty, remove and clean it. Note : The Pre-Motor Filter may be hand washed in cold water with mild detergent. -
Page 12: Check Rotating Brush And Drive Belt
Maintenance CHECK ROTATING BRUSH AND DRIVE BELT You should check your vacuum cleaner’s Rotating Floor Brush and Drive Belt regularly for wear or damage. You should also clean the brush and brush ends of strings, hair, and carpet fi bers. These can wrap around the brush and hamper its ability to effectively clean your carpet. -
Page 13: Mini Turbo Brush
Maintenance MINI TURBO BRUSH Brushbar Replacement Remove the tool from the hose, and turn upside down. Slide the switch to unlock position and remove bottom plate. Unscrew the one screw and remove belt guard. Remove brushbar including end plates and discard. Inspect belt to ensure that it is in good condition. -
Page 14: Troubleshooting
Troubleshooting Check this list of possible problems and solutions before bringing your vacuum to a service center. PROBLEM Vacuum cleaner won’t run • Power cord not plugged in • Blown fuse/tripped breaker in home Vacuum cleaner and tools won’t pick up dirt •... - Page 15 memo...
- Page 16 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. country SOUTH AFRICA Customer Care Center ☎ 0330 SAMSUNG (7267864) 0860 7267864 (SAMSUNG) Code No. DJ68-00644A REV(0.1) Web Site www.samsung.com www.samsung.com...
