Operating instructions for the end user

Turn on/off the pump (fig. 13)
By pressing the PN-button pos.1, the pneumatic switch is actuated and the pump is in ope-
ration. Press again to turn off the pump.
stream direction and beam control (fig. 13)
The stream direction can be set by the all-round swiveling nozzle pos. 2. By rotating the
nozzle you make the water jet stronger or weaker.
air control and massage (fig. 13)
By rotating the ring pos. 3 which is mounted on the nozzle, the air supply gets weaker or
stronger.
swimming against the countercurrent
Swivel the nozzle that the water layer directly below the water surface is placed in strong
current.
Use of the massage equipment (fig. 14)
Before installing or removing, the countercurrent system must be switched off. To attach the
massage unit, pull back the sliding sleeve pos. 5 and push the hose coupling in the nozzle
pos. 2. Then press the sliding sleeve against the nozzle and pull the hose back pos.6. The
hose coupling is locked. To uncouple, press the hose pos. 6 against the sliding sleeve pos.
5. Take the sliding sleeve and pull it out.
ttention:
Do not take the massage equipment closer than 30 cm to your body, you get the optimal
massage effect at full flow capacity and suitable distance.
Wintering
Drain the water to below the nozzle block. The pump must be emptied with the help of the
draining screw on the front. Only after the end of the danger of frost the drain plug can be
screwed again.
The instructions and guidelines given in this document correspond to the state of technology and
aren`t any replacement for a consultation or the carrying out by pool specialist shops or the corres-
ponding building divisions and construction companies in compliance of current building regulati-
ons. In the case of complaint, please enclose the check number and a copy of the invoice.
