Nr. term
1 built-in pot with styrofoam distance
2 seal, self-adhesive
3 flange
4 lens-head-screw M 6 x 16, 4
5 distance screw M 6 x 16, 4
6 building protection
7 check number (without illustration)
8 operating instruction (without illustration)
inventory base unit Compact 950 / 1200
Nr. term
1 pump 2,6 kW 400 V
1a pump 3,3 kW 400 V
2 nozzle frame complete
3 control box
4 air hose with valve and
implementation
5 air hose
6 PN-hose (3m)
7 PN-hose (35 cm)
8 coil spring (33 cm)
9 pump flange
The installation must exclusively be carried out by a licensed electrician. In the power line there must be
provided an all poles seperator with a contact gap of at least 3 mm. In the power line a residual cur-
rent circuit breaker with a rated leakage current must be provided of <= 30 m .
inventory installation kit
see picture 1
see picture 2
pcs Nr. Bezeichnung
1 10 flat gasket to the pump
1 11 flat gasket to the implementation
1 12 implementation to the PN-button
1 13 nut 3/ 8"
1 14 clamping collet
15 nut M8 4
1 16 washer M8 4
1 17 head screw M6x16
1 18 tube holder d 20
1 19 check number (without illustration)
1 20 operating instruction (without illustration) 1
amount
1
1
1
4
4
1
1
1
pcs
1
2
1
2
4
6
6
4
1
1
