- Page 1 FAN COIL THERMOSTAT HE-FT01 USER MANUAL for Hardware v.20 & Firmware v.2.2 HE-FT01 USER MANUAL...
-
Page 2: Table Of Contents
Time Configurations ..........................24 SETTINGS (available through Z-Wave network only) ................25 Time Mode Schedule ..........................25 Sensors Report Interval ......................... 25 Association Commands Action ......................27 PARAMETERS LIST & FACTORY DEFAULTS..................27 LIMITED WARRANTY ..........................31 HE-FT01 USER MANUAL... -
Page 3: Overview
Fan Coil Heating/Cooling Systems. The HE-FT01 is elegantly designed and „Impossibly Smart‟ providing wireless over-the-Internet control of your home‟s fan coil heating/cooling system. The HE-FT01 is „Impossibly Thin‟ on the wall yet packed with features to help you save energy while providing the ultimate comfort and convenience. -
Page 4: Technical Specifications
89mm (H) х 89mm (W) х 9mm (D) 2 independent relay inputs (dry contact) Rear electronics package dimensions: HELTUN Advanced Zero-Cross relay 53mm (H) х 53mm (W) х 28mm (D) switching technology Materials: Tempered glass Relays lifetime: 100.000 switches... -
Page 5: Installation
WARNING: ELECTRICAL POWER MUST BE SWITCHED OFF DURING INSTALLATION. 1. Placement of the HE-FT01 is of utmost importance for proper operation and must be away from sunlight and sources of direct heat. We recommend installing the HE-FT01 approximately 1.5 meters above the floor. - Page 6 HE-FT01 (various colors terminals are included in the packaging). 4. Make sure the HE-FT01 backplate is oriented on the wall with the word “TOP” pointed upwards. Then secure the backplate onto the electrical junction box using the four screws provided (do not overtighten).
-
Page 7: Disassembly
1. To disassemble, ENSURE POWER IS SWITCHED OFF at the main circuit breaker AND THE LCD SCREEN IS BLANK. 2. To remove the HE-FT01 display unit grasp firmly at the bottom and pull backwards while tilting outwards until all tabs disconnect. -
Page 8: Climate Control Modes
Heating & Cooling In this mode, the HE-FT01 switches between heating and cooling states automatically. The primary purpose of automatic climate control is to manage the temperature of the area to provide maximum comfort. This means the thermostat will heat the room when the room temperature is lower than the temperature Set Point, and it will cool the room when room temperature is higher than the Set Point. -
Page 9: Heating
"OFF" will be displayed under "SET TEMP" on the LCD. ≡ Note: According to Z-Wave protocol standards your Z-Wave gateway will show this mode as “Fan.” FAN SPEED MODES The HE-FT01 has six fan speeds: Low speed (OUT-1 is ON) Medium speed (OUT-2 is ON) ... -
Page 10: Operating Modes
Each Operating Mode (except TIME mode) has individual temperature Set Points for each Climate Mode (Heating & Cooling Modes). The HE-FT01 will operate automatically depending on the current Set Point indicated under the “SET TEMP” label on the LCD. To change the Set Point value, choose the desired Operating Mode (COM, TIME or ECO), choose the Climate Mode (“Heating”, “Cooling”... -
Page 11: Time - Temperature Schedule Mode
Set Point up or down by pressing the Plus “+” or Minus “–” buttons. Do this action for each day of the week. ≡ Note: Time for all four Schedules (Morning, Day, Evening, & Night) are the same for all seven days of the week. HE-FT01 USER MANUAL... -
Page 12: Eco - Energy Saving Mode
Note: In your Z-Wave gateway this mode will be shown as “OFF”. CHILD LOCK (LOC) The Child Lock feature allows you to disable the HE-FT01 touch buttons temporarily. To activate the Child Lock Mode, press and hold the “SPEED” button for five seconds until the Lock Icon appears in the bottom right corner of the display. -
Page 13: Factory Reset (Res)
4. Start the Inclusion Mode from the gateway/controller. 5. On the HE-FT01 in Parameter 2, press the Plus “+” key to start the Inclusion process. 6. Note that lines will be moving in the Parameter value position (bottom left corner). -
Page 14: Security
Inclusion Mode the security key should be used during the inclusion process. Security key is the first 5 digits of DSK (device DSK is printed on the HE-FT01 back panel plus on the Security Card included in the packaging). -
Page 15: Smartstart
4. Successful adding will be confirmed by displaying the Antenna with signal strength bars icon in the bottom right corner of the main screen. ≡ Note: The device DSK and QR code are printed on the HE-FT01 back panel plus on the Security Card included in the HE-FT01 packaging. Firmware OTA Update To wirelessly update the HE-FT01 firmware, follow these steps: 1. - Page 16 (S2 Authenticated, S2 Sensor Multilevel Unauthenticated or S0) highest granted (S2 Authenticated, S2 Meter Unauthenticated or S0) highest granted (S2 Authenticated, S2 Clock Unauthenticated or S0) Transport Service none Security 0 none Security 2 none HE-FT01 USER MANUAL...
-
Page 17: Associations
Association enables the HE-FT01 to control other Z-Wave devices over the network. Association Groups may include up to 5 other devices from different brands and/or manufacturers (1 device on each group 2-6). The HE-FT01 has six association groups: HE-FT01 USER MANUAL... -
Page 18: Settings Menu
OUT-5 operation. Max supported nodes: 1 ≡ Note: Through Groups 2-6 the HE-FT01 sends Basic Set command with value 0 (Off) when the relay goes to OFF state and sends 255 (On) when the relay goes to ON state. -
Page 19: Settings (Available Through Menu And Z-Wave Network)
Air Temperature Calibration․ Temperature 0.2°C … 10.0°C Configuration Temperature Hysteresis. Time correction by controller 0, 1 Time Time Format։ 0=24 hour, 1=12 0, 1 Configuration hour (AM/PM) Day of the Week 1, 2, 3, 4, 5, 6, 7 HE-FT01 USER MANUAL... -
Page 20: Z-Wave
Z-Wave Parameter 01 (“ГEg”) – Frequency Region The HE-FT01 has Z-Wave 700 series chip inside which allows to use the device in different Z-Wave frequencies. If there is a need to use the device in the frequency different from the factory default, change the value of this Parameter according to the frequency list below. -
Page 21: Hardware & Software Versions
Parameter value will be “ECL”. To include or exclude the HE-FT01 into or from your Z-Wave network, activate Inclusion or Exclusion Mode on your gateway, then go to Parameter 02 in the Device Menu and press the Plus “+”... -
Page 22: Display Brightness
Display Brightness The HE-FT01 has two brightness levels for its LCD display: Active Level – when any button is pressed the display becomes brighter, and Inactive Level – after 20 seconds of inactivity the display becomes less bright. The actual display brightness may be adjusted (see below). -
Page 23: Loads Power
Parameters 12-16, multiplied by the time measured when the HE-FT01 is active in each mode. Using your climate system specifications (see your owner‟s manual), set the load in Watts for: Fan Low Speed in Parameters 12, Fan Medium Speed in Parameter 13, and Fan High Speed in Parameter 14. -
Page 24: Temperature Configurations
For example, if the SET POINT is set for 25°C and HYSTERESIS is set for 0.5°C the HE-FT01 will change the state to IDLE if the temperature reaches 25.0°C. It will change the state to HEATING if the temperature becomes lower than 24.5°C, and will change the state to COOLING if the temperature rises... -
Page 25: Settings (Available Through Z-Wave Network Only)
Note: It is not recommended to reduce the value of this Parameter in order not to increase the traffic on your network. We recommend to reduce the value of this Parameter only in case of poor connection, when reports from the device does not always reach the gateway. HE-FT01 USER MANUAL... - Page 26 Note: When the thermostat is turning On, the sensor data will be sent to the gateway once, even if the value of this Parameter is 0. ≡ Note: It is not recommended to decrease the value of this Parameter, in order not to increase the load on your Z-Wave network traffic. HE-FT01 USER MANUAL...
-
Page 27: Association Commands Action
This Parameter defines which Operating Mode the HE-FT01 reverts to if the Basic Set command is received. If the Basic Set command value is 0 (OFF state) the HE-FT01 will go to OFF mode and switch the operating state to IDLE. If the Basic Set command value is 0xFF (ON state) the HE-FT01 will change the Mode to the corresponding Parameter value (as follows). - Page 28 08:00 = 0800 2 bytes Day start time. Format: HHMM. 0000…2359 2 bytes Evening start time. Format: HHMM. 1800 0000…2359 2 bytes Night start time. Format: HHMM. 2300 0000…2359 10 … 370 2 bytes Monday Morning temperature, valueX10 HE-FT01 USER MANUAL...
- Page 29 Friday Morning temperature, valueX10 10 … 370 2 bytes Friday Day temperature, valueX10 10 … 370 2 bytes Friday Evening temperature, valueX10 10 … 370 2 bytes Friday Night temperature, valueX10 Saturday Morning temperature, 10 … 370 2 bytes valueX10 HE-FT01 USER MANUAL...
- Page 30 0, 1 … 25 1 byte Light sensor values difference to send to 0, 10 … 99 1 byte controller, % 147-170 Reserved by the manufacturer Mode to switch to on Basic Set 0,1,2,3,4,5 1 byte command receive 6,7,8,9 HE-FT01 USER MANUAL...
-
Page 31: Limited Warranty
LIMITED WARRANTY HELTUN warrants this product to be free from defects in workmanship or materials, under normal use and service, for a period of one (1) year from the date of purchase by the consumer ("Warranty Period"). HELTUN will extend this Warranty Period to three (3) years from the date of consumer purchase for any consumer who registers his/her product with HELTUN at this website page: bonus.heltun.com.
