Fitting/replacing bulbs
• The LEDs in this product are non-replaceable.
Battery Replacement
• If after routine operation check, the lamp does not remain
lit for the three hour period, a new battery pack may be
required.
• Switch off the electricity at the mains, allow batteries to
fully discharge then reconnect to supply and allow to
charge for 24 hours.
• Test again for two hours, if light does not remain lit
change the battery pack as follows:
• Undo the screw under the front panel and lift panel away
from fitting. Keep screw safe for refitting later.
• Unplug the battery lead from the lead coming from the
PCB. Remove any cable ties around the cables.
• Remove the battery pack. Waste electrical products should
not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority or
retailer for recycling advice.
Cleaning Information
• We recommend cleaning with a soft dry cloth or wash
with warm water or just use a damp cloth.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
Safety information
Live Voltages may be present in this unit even when turned of or when completely disconnected.
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part should be scrapped.
This bulbs are protected by shades. This part must be replaced immediately should the shades
become cracked or damaged. This fitting must not be used without the shades in place.
www.saxbylighting.com
• Replace the battery with a 3.6V 4500mAh Ni-Cd ONLY.
Use of a different type of battery will damage the product.
• Write current date on the new battery pack.
• Fit the new battery pack in position and re secure using
the screws set aside earlier. Refit the cable ties in
position and then plug battery pack into the PCB.
• Refit the front panel with the screw set aside earlier.
• Perform full operation check and update test record.
• Restore power and allow to charge for 24 hours..
• Do not use abrasive materials as these will damage the
finish.
Iss 1 22052017
Saxby Lighting. BH23 3PE
Instruction leaflet
Sight Twin Spot
72642
