DSI Dynamatic AS-703 Instruction Manual page 23

Typical Cross Section Drawing – AS-704
Model AS-704 Parts List
Item No.
1 Key
2 Cap Screw, Lockwasher
Field Assembly
3
4 Housing
5 Bearing
6 Shaft (double shaft extension)
7 Snap Ring
8
Rotor
9 Fan
10 Key
11 Screen
12 Tube Insulator
13 Pipe Plug
14 Grease Fitting
15 Cotter Pin
16
Spring
23
Description
(single shaft extension)
Figure 5-2
DY-1641
DY-132, DY-77
B-64018-(See Master Bill)
D-32304
DY-12814
C-32303
C-53395
DY-1476
C-32297
C-32296
DY-1186
A-32306-0200
A-71605-0100
DY-1472
DY-1336
DY-340
A-18973
Table 5-2
Part Number
Ref.: D-64016
