Typical Cross Section Drawing – AS-703
Model AS-703 Parts List
Item No.
1 Key
2 Cap Screw, Lockwasher
Field Assembly
3
4 Housing
5 Bearing
6 Shaft (double shaft extension)
7 Retaining Ring
8
Fan
9
Key
10 Screen
11 Rotor
12 Cotter Pin
13 Spring
14 Grease Fitting
Pipe Plug
15
21
Description
(single shaft extension)
Part Number
DY-373
DY-10311, DY-4771
B-64018-(See Master Bill)
D-64027-0100
DY-12814
C-32295
C-34901
DY-1476
C-32296
DY-1186
A-32306-0100
B-32297
DY-340
A-18973
DY-82
DY-1472
Figure 5-1
Table 5-1
Ref.: D-64019
