  • Page 1 SyncMaster 194T...
  • Page 2 Main Page Safety Instructions Notational Power Installation Cleaning Other Introduction Unpacking Front Rear Setup Connecting the Monitor Installing the Monitor Driver Automatic Manual Installing VESA compliant mounting On-Screen Display Troubleshooting Check List Q & A Self-Test Feature Check Specifications General Specifications PowerSaver Preset Timing Modes Information...
  • Page 3 Notational Power Installation Clean Other Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. Prohibited Do not disassemble Do not touch Important to read and understand at all times Disconnect the plug from the outlet Grounding to prevent an electric shock...
  • Page 4 Notational Power Installation Clean Other When not used for an extended period of time, set your computer to DPMS. If using a screen saver, set it to the active screen mode. Do not use a damaged or loose plug. This may cause an electric shock or fire. Do not pull the plug out by the wire nor touch the plug with wet hands.
  • Page 5 Notational Power Installation Clean Other Put your monitor in a location with low humidity and a minimum of dust. An electric shock or fire could result inside the monitor. Do not drop the monitor when moving it. This may cause damage to the product or human body. Place the monitor on a flat and stable surface.
  • Page 6 Notational Power Installation Clean Other When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a slightly moistened, soft fabric. Do not spray water or detergent directly on the monitor. This may cause damage, electric shock or fire. Use the recommended detergent with a smooth cloth.
  • Page 7 Notational Power Installation Clean Other Do not remove cover(or back). This may cause an electric shock or fire. Refer servicing to qualified service personnel. If your monitor does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or This may cause an electric shock or fire.
  • Page 8 Do not use or store inflammable substances near the monitor. This may cause an explosion or fire. Never insert anything metallic into the monitor openings. This may cause an electric shock, fire or injury. Do not insert metal objects such as utensils, wire or drill bits, or things that catch fire easily, such as pieces of paper or matches, into the vents, the headphone or A/V ports on the monitor.
  • Page 9 When moving the monitor, turn the power switch off and unplug the power cord. Make sure that all cables, including the antenna cable and cables connected devices, are disconnected before moving the monitor. Failure to disconnect cables may damage it and lead to fire or an electric shock.
  • Page 10 Unpacking Front Rear Please make sure the following items are included with your monitor. If any items are missing, Monitor and Stand contact your dealer. Power Cord DVI Cable 'DVI-A to D-SUB' Cable Quick Setup Guide Warranty Card (Not available in all locations) User's Guide and Monitor Driver Natural Color software, Pivot®...
  • Page 11 Unpacking Front Rear 1. Auto button 2. Enter button [ ] / Source button 3. MagicBright button MagicBright is a new feature providing optimum viewing environment depending 4. Adjust buttons 5. Menu button / Exit button 6. Power button 7. Power indicator Note: See PowerSaver For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for...
  • Page 12 Unpacking Front Rear (The configuration at the back of the monitor may vary from product to product.) 1. Power port 2. 1(DVI-I) port 3. 2(DVI-I) port 4. Pin 5. Power on/off Switch Note: See Connecting the Monitor Connect the power cord for your monitor to the power port on the back of the monitor.
  • Page 13 If you properly connect your monitor using the DVI-I connector but get a blank or fuzzy screen, check to see if the monitor status is set to analog. Press Source button to have the monitor double-check the input signal source. For the best quality of display,please use a signal cable which Samsung provides.
  • Page 14 5. Monitor driver installation is completed. Windows XP/2000 1. Insert CD into the CD-ROM drive. 2. Click "Windows XP/2000 Driver". 3. Choose your monitor model in the model list, then click the "OK" button. http://www.samsung-monitor.com/ http://www.samsungusa.com/monitor/ http://www.sec.co.kr/monitor/ (Korea) http://www.samsungmonitor.com.cn/ (Worldwide)
  • Page 15 5. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button. This monitor driver is under certified MS logo,and this installation doesn't damage your system.The certified driver will be posted on Samsung Monitor homepage. http://www.samsung-monitor.com/. 6. Monitor driver installation is completed.

  • Page 16: Windows Xp Operating System

    2. Click "Start" —> "Control Panel" then click the "Appearance and Themes" Icon. 3. Click "Display" icon and choose the "Settings" tab then click "Advanced..". 4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Windows 2000 Windows Me Windows NT http://www.samsung-monitor.com/ http://www.samsungusa.com/monitor/ http://www.sec.co.kr/monitor/ http://www.samsungmonitor.com.cn/ ® ®...
  • Page 17 5. Click "Update Driver.." and select "Install from a list or.." then click "Next" button. 6. Select "Don't search ,I will.." then click "Next" and then click "Have disk". 7. Click the "Browse" button then choose A:(D:\Driver) and choose your monitor model in the model list and click the "Next"...

  • Page 18: Microsoft ® Windows ® 2000 Operating System

    This monitor driver is under certified MS logo,and this installation doesn't damage your system.The certified driver will be posted on Samsung Monitor homepage. http://www.samsung-monitor.com/. 9. Click the "Close" button then click "OK" button continually. 10. Monitor driver installation is completed.

  • Page 19: Linux Operating System

    4. Select the "Monitor" tab. 5. Click the "Change" button in the "Monitor Type" area. 6. Choose "Specify the location of the driver". 7. Choose "Display a list of all the driver in a specific location.." then click "Next" button. 8.
  • Page 20 Using the Stand Pivot Pro Installation Connecting the Monitor Installing the Removing the base Monitor Driver Installing VESA compliant mounting 1. Turn off your monitor and unplug its power cord. 2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen.
  • Page 21 the four screws that came with the arm-type base, wall mount hanger or other base. Pivot Stand...
  • Page 22 Using the Stand Pivot Pro Installation Connecting the Monitor Pivot Pro Installation Installing the Monitor Driver 1) Insert the Pivot Pro CD-ROM into the CD-ROM drive. Installing VESA compliant 2) Click the START_Pivot installation file. mounting 3) Select installation Language. 5) Starting installation.
  • Page 23 7) Select a User Name and Organization to install Pivot Pro. Then Click[Next]. 8) Click [Install] to start installing Pivot Pro. 9) Install Pivot Pro in the selected location. 10) Pivot Pro has been successfully installed. Click [Finish].
  • Page 25 User Control Buttons 1. Press to self-adjust to the incoming PC signal. The values of fine,coarse and position are adjusted automatically. 2. Press this button activates a highlighted menu item. 3. This buttons allows you to adjust items in the menu. 4.
  • Page 26 Direct Functions AUTO Menu When the 'AUTO' button is pressed, the Auto Adjustment screen appears as shown in the animated screen on the center. Auto adjustment allows the monitor to self-adjust to the incoming video signal. The values of fine, coarse and position are adjusted automatically. (Available in analog Mode Only) AUTO To make the automatic adjustment function sharper, execute the 'AUTO' function...
  • Page 27 MagicBright™ Menu Then push the MagicBright button again to circle through available preconfigured modes. MagicBright™ - Four different modes(Custom/Text/Internet/Entertain) Brightness Menu Brightness When OSD is not on the screen, push the button to adjust brightness. Description Description...
  • Page 28 Source Menu Source Selects the Video signal while the OSD is off. Osd Functions Brightness Contrast 1. Picture Color Tone Color Control 2. Color Coarse Fine 3. Image Language H-Position 4. OSD Auto Source Image Reset 5. Setup 6. Information Picture Menu Description...
  • Page 29 You anc use the on-screen menus to change the brightness according to personal preference. Brightness Direct Access Feature : When OSD is not on the screen, Push the button to adjust brightness. You can sue the no-screen menus to change the contrast Contrast according to personal preference.
  • Page 30 Image Menu Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center Coarse using the Horizontal Control menu. (Available in analog Mode Only) Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency Fine (clock speed).
  • Page 31 Menu Description Play/Stop You can choose one of seven languages. (English, German, Spanish, French, Italian, Swedish, Russian) Language Note:The language chosen affects only the language of the OSD. It has no effect on any software running on the computer. You can change the horizontal position where the OSD menu H-Position appears on your monitor.
  • Page 32 Setup Menu Select Auto Source for the monitor to automatically select the Auto Source signal source. Image Reset Image parameters are replaced with the factory default values. Color Reset Color parameters are replaced with the factory default values. This is a source-switch function according to the priority that the Priority user has set for the source.

  • Page 33: Check List

    Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call Information section or contact your Check List Symptom Q & A Self-Test Feature No images on the Check screen.

  • Page 34: The Screen Suddenly Has Become Unbalanced

    Is the screen displaying only one The screen shows color as if looking at the screen strange colors or just black and white. through a cellophane paper? Have the screen colors become strange after running a program or due to a crash between applications? Has the video card been set properly?
  • Page 35 How can I change the frequency? Check List Q & A Self-Test Feature Check How can I adjust the resolution? How can I set the Power Saving function? How can I clean the outer case/LCD Panel? Question Frequency can be changed by reconfiguring the video card.
  • Page 36 Your monitor provides a self test feature that allows you to check whether your monitor is Check List functioning properly. Q & A Self-Test Feature Check 1. Turn off both your computer and the monitor. 2. Unplug the video cable from the back of the computer. 3.
  • Page 37 The location and the position of the monitor may influence the quality and other features of the monitor. 1. If there are any sub woofer speakers near the monitor, unplug and relocate the woofer to another room. 2. Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor.

  • Page 38: Power Consumption

    General Model Name LCD Panel General Size PowerSaver Preset Timing Display area Modes Pixel Pitch Type Synchronization Horizontal Vertical Display Color 16.7 Million Resolution Optimum resolution Maximum resolution Input Signal, Terminated RGB Analog , DVI(Digital Visual Interface) Compliant Digital RGB. 0.7Vp-p ±5%, Positive bright, 75 ohms ±10%(terminated), Separate H/V sync, Composite, SOG, TTL level, positive or negative Maximum Pixel Clock...
  • Page 39 TFT LCD panel manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above is used for this product. But the pixels of RED, GREEN, BLUE and WHITE color seem to be bright sometimes or some of black pixels could be seen. This is not from bad quality and you can use it without uneasiness.
  • Page 40 TAR ® This monitor is EPA E NERGY when used with a computer equipped with VESA DPMS functionality. TAR ® As an E Partner, SAMSUNG has determined that this product NERGY TAR ® meets the E guidelines for energy efficiency. NERGY...

  • Page 41: Horizontal Frequency

    If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1.
  • Page 42 The address and phone number of the company can be changed without previous notice. AUSTRALIA : Service Samsung Electronics Australia Pty Ltd. Terms Customer Response Centre Regulatory 7 Parkview Drive, Homebush Bay NSW 2127 Tel : 1300 362 603 Natural Color http://www.samsung.com.au/...
  • Page 43 TEL: 01-55-5747-5100 / 01-800-726-7864 Fax: 01-55-5747-5202/ 01-800-849-1743 RFC: SEM950215S98 http://www.samsung.com.mx/ IMPORTADO POR: SAMSUNG ELECTRONICS MÉXICO. S.A. DE C.V. Vía Lopez Portillo No. 6, Col. San Fco. Chilpan Tultitlán, Estado de México, C.P. 54940 TEL: 01-55-5747-5100 / 01-800-726-7864 EXPORTADO POR: Samsung Electronics CO.,LTD.
  • Page 44 MPA COMPLEX BUILDING,1st-2nd Floor 175 SOI SUEKSA VIDHAYA SATHON SOI 12 SILOM ROAD ,SILOM,BANGRAK BANGKOK 10500 TEL : 0-2635-2567 FAX : 0-2635-2556 UKRAINE : SAMSUNG ELECTRONICS REPRESENTATIVE OFFICE IN UKRAINE 4 Glybochitska str. Kiev, Ukraine Tel. 8-044-4906878 Fax 8-044-4906887 Toll-free 8-800-502-0000 http://www.samsung.com.ua/ United Kingdom : Samsung Electronics (UK) Ltd.
  • Page 45 Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Service Vertical Frequency Terms The screen must be redrawn several times per second in order to create and display an image...
  • Page 46 Federal Communications Commission. It is available from the U.S. Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4. The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA Tel) 949-975-7310...
  • Page 47 Equipment Regulations of ICES-003. Cet appareil Numérique de classe B respecte toutes les exigences du Règlemont NMB-03 sur les équipements produisant des interférences au Canada. MPR II Compliance This monitor complies with SWEDAC(MPR II) recommendations for reduced electric and magnetic fields.

  • Page 48: Environmental Requirements

    In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment.The main problem as far as monitors and other electronic equipment are concerned is that environmentally harmful substances are used both in the products and during their manufacture.
  • Page 49 Mercury Mercury is sometimes found in batteries, relays and switches. Mercury damages the nervous system and is toxic in high doses. TCO'95 requirement states that batteries may not contain more than 25 ppm (parts per million) of mercury. It also demands that no mercury is present in any of the electrical or electronics components concerned with the display unit.
  • Page 50 SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire.
  • Page 51 For recycling information for TCO'03 certified monitors, for the residents in the following countries, please contact the company corresponding to your region of residence. For those who reside in other countries, please contact a nearest local Samsung dealer for recycling information for the products to be treated in environmentally acceptable way.
  • Page 52 Mercury Statement (LCD Monitor, LCD TV, DLP Projection TV, Projector for USA only) LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS For details see lamprecycle.org, eiae.org, or call 1-800-Samsung...
  • Page 53 For more information, refer to Help (F1) in the software program. How to install the Natural Color software Insert the CD included with the Samsung monitor into the CD-ROM Drive. Then, the initial screen of the program installation will be executed. Click Natural Color on the initial screen to install the Natural Color software.
  • Page 54 For Better Display 1. Adjust computer resolution and screen injection rate (refresh rate) on computer as described below to enjoy the best quality of picture. You can have an uneven quality of Service picture in the screen if the best quality of picture is not provided in TFT-LCD. Terms Regulatory Natural Color...
  • Page 55 PRODUCT INFORMATION (Image Retention Free) Service LCD Monitors and TVs may have image retention when switching from one image to another especially after displaying a stationary image for a long time. Terms This guide is to demonstrate correct usage of LCD products in order to protect them from Image Regulatory retention.
  • Page 56 - Every 30 minutes, change the characters with movement. The best way to protect your monitor from Image retention is to set your PC or System to operate a Screen Saver program when you are not using it. Image retention may not occur when a LCD panel is operated under normal conditions. Normal conditions are defined as continuously changing video patterns.
  • Page 57 Our LCD Monitor satisfies ISO13406-2 Pixel fault Class II...
  • Page 58 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Service Co., Ltd. is strictly forbidden. Terms Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or Regulatory consequential damages in connection with the furnishing, performance, or use of this material. Natural Color For Better Display Samsung is the registered trademark of Samsung Electronics Co., Ltd.;...
