INSTALLATION AND SERVICE MANUAL
Please fill in for future reference:
ModEl: ___________________________
sErial nuMBEr: ____________________
datE PurcHasEd: ___________________
* Please fill out the warranty registration card
in this manual or online at www.mdminc.com
TYPE: End-suction cEntrifugal
MOTOR: nEMa 143JM-215JM
PORT SIZE: 3" flangEd inlEt, 2" flangEd discHargE
WARNING: Please read completely before you install or operate your new pump! do not allow this pump to become submerged!
never run dry - never reverse rotation. never exceed an internal case pressure of: 100 Psi.
Proudly Assembled in the USA
Sustainable, Efficient.
TITAN
®
XXXXXXXXX
S/N: XXXX-XXXXXX
HORSEPOWER: 3/4 HP tHrougH 15 HP
HARDWARE: stainlEss stEEl
SEAL OPTIONS: stainlEss stEEl WitH Buna and Viton
© 2009 MDM INC.
Advertisement
Related Manuals for MDM Sequence Titan
Summary of Contents for MDM Sequence Titan
- Page 1 WARNING: Please read completely before you install or operate your new pump! do not allow this pump to become submerged! never run dry - never reverse rotation. never exceed an internal case pressure of: 100 Psi. Sustainable, Efficient. © 2009 MDM INC. Proudly Assembled in the USA...
-
Page 2: Installation
Verify motor rotation with rotation meter. incorrect rotation can cause serious damage to pump and/or motor. MdM does not recommend checking rotation by quickly switching power on and off because serious damage can occur. - Page 3 Eye protection is strongly recommended. (if you are replacing the seal) detach bracket from motor. remove mechanical seal from bracket by pressing out from the back. do not dig out from the front! (if you are replacing the seal). Sustainable, Efficient. © 2009 MDM INC. Proudly Assembled in the USA...
-
Page 4: Pump Schematic
(1/2”-13 x 1.25” LG for frame sizes 213JM and larger) 5.25 FIG. 1 WASHER, FLAT, 3/8” X 1.0” OD, SS (1/2” WASHER for frame sizes 213JM and larger) Corrosion-resistant, non-metallic pumps. © 2009 MDM INC. Proudly Made in the USA... -
Page 5: Maintenance
Some states do not allow limitations on how long an implied warranty of purchase, the sole obligation of MdM, incorporated (hereinafter referred to as MdM) will be to repair the unit or replace with lasts, so the above limitation may not apply to you.
