Multi-Channel, Multi-Sensor Controller
Do you have these problems?
There are too many types of sensors (pressure, flow, etc.) inside the equipment...
Monitoring and controlling each sensor is too complicated!
Are you
troubled?
1 controller centrally manages any 4 sensors
with outputs of 1 to 5 V* !
Plus, with the RS485 communication type,
Best
Answer!
up to 16 controllers can be centrally
managed! (Maximum of 64 sensor heads)
* Including other manufacturer's products
RS232C
communication
RS485
communication
Pressure and
flow sensor
heads are
available
MSU Series
Added PNP output type
NEW
Connect any
sensor with 1 to
5 V output
5 output mode
Catalog No.BK-A5046
patterns
*Only NPN type is UL compliant.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSU Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Koganei MSU Series

  • Page 1 RoHS compliant ISO 9001 / ISO 14001 product Multi-Channel, Multi-Sensor Controller MSU Series Do you have these problems? There are too many types of sensors (pressure, flow, etc.) inside the equipment... Monitoring and controlling each sensor is too complicated! Are you...
  • Page 2 MSU Series Multi-channel multi-sensor controller Extensive output settings can support your application! Output mode setting • Hysteresis Mode • Window comparator mode 1 (mode that does not turn on when between L1 and L2 while rising) Mode for setting the ON point and OFF point...
  • Page 3 1 controller centrally manages multiple sensors! Example connection 1 Upper controller 4 point switch output Pressure sensor head 4 point switch output Flow rate sensor head Any 1 to 5 V sensor MSU-232 Example connection 2 Equipped with communication mode compatible with existing models Command communications + 4 point switch output Upper controller MSU-232...
  • Page 4: Safety Precautions

    ● Use countermeasures for heat dissipation so that the ambient ● Because Koganei products may be used under a wide variety of temperature of the product stays within the specified temperature conditions, decisions concerning conformance with a particular...
  • Page 5: General Precautions

    Koganei products. short-circuited may damage the products due to over current. (4) Koganei is not responsible for any losses due to use or storage Example of short-circuit load: Output lead wire for sensor output (SW output) of the product in a way that is outside of the product is directly connected to the power supply.
  • Page 6: Attaching The Mounting Bracket

    Handling Instructions and Precautions Attaching and removing of the sensor head, and the Sensor head and connector connection procedure power supply, switch, and communication cable When the sensor head MSU-PH-□-□ is supplied, the sensor head body and mini clamp connector (male) are not yet connected. Follow 4-sensor head connector Power connector Comxmunication...
  • Page 7: Specifications

    Specifications List of controller specifications Item Specifications Up key: △ Down key: ▽ Enter key: Main unit keys Item Specifications Communications RS232C RS485 12 to 24 VDC ±10% *Use a Class 2 standard Voltage power supply. 9600, 19200, Communication Power Sensor head supply 12 to 24 VDC ±10% (*Depending on 9600, 19200 bps...
  • Page 8: Wiring Specifications

    Wiring specifications for the controller <MSU-□, MSU-232-□> <MSU-485-□> Wiring specifications Connector type Item Specifications Connector type Item Specifications 1 pin : 24V (red) Pin 1: 24 V (red) Power supply Power supply 2 pin : 0V (black) Pin 2: 0 V (black) 3 pin : SW1 (white) Pin 3: SW1 (white) Manufactured by JST...
  • Page 9: Circuit Diagram

    Wiring When connecting, refer to the figure below and use the provided power and signal cables. CAUTION ● In case noise generating equipment (switching regulator, inverter motor, etc.) is used in the vicinity of this sensor, connect the frame ground (F.G.) terminal of the equipment to an actual ground. Additionally, when selecting a power supply, choose one that is Class 2. ●...
  • Page 10: Order Codes

    Order Codes ● Sensor controller MSU - Cable(*2) Blank: None 3L: 3000 mm [118 in.] power supply, switch cable (for no MSU communications) Front protection cover (*1) 5L: 5000 mm [197 in.] power supply, switch cable (for no MSU communications) Blank: None 3LD: 3000 mm [118 in.] power supply, switch, communication cable (for MSU-232) C: With protective...
  • Page 11 Dimensions (mm [in.]) ● MSU Enlarged diagram of wiring labels   MSU-232 * The label above shows the MSU-232. No communication/RS-232C communication specification For the MSU (no communications), 7 to 9 are N.C. * Only NPN type is UL compliant. 27.6 [1.087] 8.3 [0.327] 40 [1.575]...
  • Page 12 MSU-PH-ER-□-UR□ MSU-PH-ER-□-M5 MSU-PH-EM-□-UR□ MSU-PH-EM-□-M5 For -L For -L (3000 [118]) For -S (3000 [118]) KOGANEI MADE IN JAPAN KOGANEI MADE IN JAPAN φ2 [0.079] (pressure port) For -S 2-M3, depth 3 [0.118] 2-M5, depth 4 [0.157] φ6 [0.236] (for -UR6) 4 [0.157]...
  • Page 13 Dimensions (mm [in.]) ● MSU-K-□HE 23.4 [0.921] 10 [0.394] 13.4 [0.528] Pin 1 Pin 1 15.6 [0.614] (20 [0.787]) (20 [0.787]) Model MSU-K-3HE 3000 [118] MSU-K-5HE 5000 [197] Mini clamp wire Mini clamp wire mount plug mount socket ● MSU-K-□L ●...
  • Page 14 ■ Introduction to New Products (Separate Type Multi-Channel Flow Rate Sensor Controller Series) Specifications ● Flow rate sensor head * Not UL/CE compliant. Model FS-R3 FS-R05 FS-10 Item Air or nitrogen, however, the detected fluid must not contain any salt, sulfur, acid, or other corrosive elements. Also, air must be dry. Measurement target gas Clean gas that does not include any dust or mist (oil mist).
  • Page 15 Flow rate sensor head [flow rate] - [output characteristics] charts ● FS-R05 ● FS-R3 ● FS-10 1 ℓ /min (ANR) = 0.035 ft /min (SCFM) [Flow rate]-[Output] characteristics [Flow rate]-[Output] characteristics [Flow rate]-[Output] characteristics −3.0 −2.5 −2.0 −1.5 −1.0 −0.5 0.0 0.5 1.0 1.5 2.0 2.5 3.0 −500 −400 −300 −200 −100 100 200 300 400 500 0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0...
  • Page 16 Limited Warranty • KOGANEI CORP. shall in no way be liable or responsible for KOGANEI CORP. warrants its products to be free from defects injuries or damage to persons or property arising out of the in material and workmanship subject to the following provisions.
