METIS M311 / M322 / H311 / H322 (12-pin)
7.3.2.2 Service functions
create service files for remote diagnosis of problems.
 Create configuration file: A configuration file (
all pyrometer data and device settings that have been made. This can be used
e.g. to setup a new pyrometer with the same values and settings or to save the
current status in case of a device replacement.
 Load Configuration file: Load a previously saved configuration data in the py-
rometer.
 Print parameters: Prints the parameters of the currently connected device.
 Print configuration file: Prints a saved file.
 Factory Settings: Resets the device to its factory defaults.
 Create service file: A service file includes all device data and all software set-
tings made by user. Creating such a file can be useful if a problem can't be solved and help from our service
could be useful.
 Upload service file: Transmitting a (possibly modified) file to the device it was created from.
7.3.2.3 Interface
(see 6.2.16) or interface delay / answer delay) (see 6.2.17).
7.3.2.4 Data Collection (Buffer Mode)
requirements and computing power. Speed and transferable amount of data are dependent on the baud rate
and the data mode. In the data collection window the amount of measured values are shown, determined by
calculation for each baud rate and each mode. When set to "Auto. interval adjustment", the corresponding val-
ues of baud rate selection will be entered automatically in the field on bottom right. When required, they still
can be adjusted manually, for example, if the calculated values still give problems.
To back-up, for printing or restore device parameters or
For setting the baud rate (see 6.2.15), device address
The measurement data transfer from pyrometer to the PC can vary depending on the
data format * .r2p) contains
