Hardware Configuration - GIT G-scan Tab Quick Manual

1. Hardware Configuration

GVCI Specification
Memory
Operating Voltage
Dimension / Weight
Wireless protocol
Indicators
Supported Protocols
System Requirements (Tablet)
Display
CPU
RAM
Storage (C:)
OS
Wireless protocol
Included Components
GVCI Module (1EA)
Specification & System Requirement
Flash Memory 2MByte / SRAM 256KByte
7~30VDC
58 X 74 X 36 mm / 90g
Bluetooth 2.1 + EDR (2.4GHz )
1 LED (Front)
CAN (High Speed, Low Speed, Single Wire)
ISO-9141, ISO-9141-CARB, KWP-2000
SAE J1850 (VPWM,PWM)
Melco Pull-Down
1200X800 or higher
Intel Bay Trail -TZ3735F 64bit processor or later with greater performance
2 GB or more
15 GB or more free space
Windows 10 (or later version)
Bluetooth 2.0 or higher
Extension Cable (1EA)
P. 2
