Summary of Contents for Parker GS Global Resources V12 Series
- Page 1 Bulletin HY30-8223-INST/EU Installation and start-up information Hydraulic Motors Series V12, V14 and T12 Visit our homepage for additional support parker.com/pmde Effective: August 22, 2016 Supersedes: March 12, 2014...
- Page 2 - Refer to the V14 illustration below right. cap position T). NOTE: Before installing a V12, V14 or T12 motor in series (when both A and B ports can be subject to high pressures simultaneously) contact Parker Hannifin. Port A Port B Left Right hand...
-
Page 3: Case Pressure
To secure correct case pressure and lubrication, a spring loaded check valve, 1-3 bar, in the drain line (shown on next page) is recommended. NOTE: Contact Parker Hannifin for information when operating at high speeds. Min and max case pressure [bar] vs. shaft speed [rpm]. - Page 4 Drain port Drain port Alt. drain port Check valve Recom- mended 1-3 bar Alt. drain port To reservoir Alt. drain ports V14_drain.eps V14 shown V14 shown Fig. 3. Fig. 2. Leif A./03-03-11 Parker Hannifin Pump & Motor Division Europe Trollhättan, Sweden...
-
Page 5: Hydraulic Fluids
The ideal operating range for the motor is 15 to 30 mm Fire resistant fluids, when used under modified opera-ting conditions, and synthetic fluids are also suitable. Contact Parker Hannifin for additional information about: - Hydraulic fluid specifications - Fire resistant fluids. - Page 6 High Speed / High Power operation Running in procedure at mid. displacement Running in procedure Parker Motors We suggest the following procedure to run in the V12/V14/T12 motors. 1. Start @ 500 rpm, differential pressure 250 bar, outlet 10-15 bar.
- Page 7 The user must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalog and in any other materials provided from Parker or its subsidiaries or authorized distributors.
- Page 8 Declaration Position notification regarding Machinery Directive 2006/42/EG: Products made by the Pump & Motor Division Europe (PMDE) of Parker Hannifin are excluded from the scope of the machinery directive following the “Cetop” Position Paper on the implementation of the Machinery Directive 2006/ 42/ EC in the Fluid Power Industry.
