SymCom PumpSaver Plus 234-P Installation Instructions Manual page 6

RUN HOURS / FAULT HISTORY
®
The PumpSaver
®
PumpSaver Plus Informer (see USING AN INFORMER). Run hours and fault history can be
cleared on the PumpSaver
p rocedure.
NOTE: Turn the SENSITIVITY knob completely to the left (counter-clockwise) or completely
t o the right (clockwise) when directed. The knob must be turned in quick succession.
To Reset Run Hours and Clear Fault History:
1. Remove power to the PumpSaver
2. Set the RESTART DELAY/CALIBRATION knob to RESET and the SENSITIVITY knob to the
middle (12:00) position.
3. Apply power to the PumpSaver
4. Turn the SENSITIVITY knob to the right—the CAL. LIGHT will turn off and the RUN LIGHT will
turn on.
5. Turn the SENSITIVITY knob to the left—both lights will turn on.
6. Turn the SENSITIVITY knob to the right.
7. After 10 seconds, the CAL. and RUN LIGHTS will blink twice indicating the run hours and fault
history have successfully been cleared.
RAPID CYCLING
Rapid cycling is defined as more than 4 restarts in a 60-second period. The PumpSaver
capable of detecting a rapid-cycle condition whether a control device, such as a pressure switch,
is installed before* or after it. Upon detecting either form of rapid cycling, the PumpSaver
lock-out, preventing damage to the pump. To reset the PumpSaver
power.
R APID CYCLING (Line Side / Upstream)
Rapid cycling of the line side of the PumpSaver
occurring conditions which are indistinguishable from true rapid cycling. For this reason, once
tripped, the PumpSaver
pump runs for more than one minute), the rapid cycle counter will reset to zero. If the
®
PumpSaver Plus encounters rapid cycle 4 times without a successful restart, it will lock-out and
r equire a manual reset. To reset the PumpSaver
*Protection against rapid cycling of a control device installed before the PumpSaver
disabled by default. Read the following instructions fully before performing the procedure to
e nable his feature.
NOTE: Turn the SENSITIVITY knob completely to the left (counter-clockwise) or completely
to the right (clockwise) when directed. The knob must be turned in quick succession.
To Enable Line Side / Upstream Rapid-Cycle Protection: (to disable, follow the same
p rocedure)
1. Remove power to the PumpSaver
2. Set the RESTART DELAY/ CALIBRATION knob to RESET and the SENSITIVITY knob to the
middle (12:00) position.
3. Apply power to the PumpSaver
4. Turn the SENSITIVITY knob to the right—the CAL. LIGHT will turn off, RUN LIGHT will turn on.
5. Turn the SENSITIVITY knob to the left—both lights will turn on.
6. Turn the SENSITIVITY knob right—left—right—left—right.
© 2009 SymCom, Inc. All Rights Reserved
Plus records pump run hours and fault history. This data can be displayed by a
®
Plus. Read the following instructions fully before performing the
®
®
Plus —the CAL. LIGHT will turn on.
®
Plus will wait 30 minutes and restart. If the restart is successful (the
®
®
Plus —the CAL. LIGHT will turn on.
Plus.
®
Plus may be caused by several naturally
®
Plus, remove and re-apply power.
Plus.
®
®
Plus, remove and re-apply
®
Plus is
Plus will
®
Plus is
6
