SAFETY AND OPERATING MANUAL
Mig Master
MIG100/MIG130
ORIGINAL INSTRUCTIONS
MIG100/MIG130

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mig Master MIG100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Autojack Mig Master MIG100

  • Page 1 SAFETY AND OPERATING MANUAL Mig Master MIG100/MIG130 ORIGINAL INSTRUCTIONS MIG100/MIG130...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Welcome to Autojack! Dear customer, Congratulations on your purchase. Before using the Product for the first time please be sure to read these instructions for use. They provide you with all information necessary for using the product safely and to ensure its long service life.
  • Page 3: General Power Tool Safety Warnings

    GENERAL POWER TOOL SAFETY WARNINGS d) Do not abuse the cord. Never use the cord for WARNING Read all safety warnings and carrying, pulling or unplugging the power tool. all instructions Failure to follow the warnings Keep cord away from heat, oil, sharp edges or and instructions may result in electric shock, fire moving parts.
  • Page 4 GENERAL POWER TOOL SAFETY WARNINGS e) Do not overreach. Keep proper footing and e) Maintain power tools. Check for misalignment balance at all times. This enables better control or binding of moving parts, breakage of parts and of the power tool in unexpected situations. any other condition that may affect the power tool’s operation.
  • Page 5 GENERAL POWER TOOL SAFETY WARNINGS c) When Battery pack is not in use, keep it away e) Wear insulating gloves on both hands for from other metal objects, like paper clips, coins, welding. These offer protection from electric keys, nails, screws or other small metal object shocks (idling voltage in the welding circuit), that can make a connection from one terminal harmful radiation (Heat and UV radiation) and...
  • Page 6 GENERAL POWER TOOL SAFETY WARNINGS l) Special regulations apply in areas where there 8 Additional Safety Instructions for is a potential risk of fire and/or explosion. Constricted and wet areas m) Welds that are exposed to large stresses and When working in constricted, wet or hot areas, must comply with safety requirements may only use insulating supports and intermediate layers as be completed by specially trained and approved...
  • Page 7 GENERAL POWER TOOL SAFETY WARNINGS 10 Additional Safety Instructions for 11. Using an Extension Cable Protection from radiation and burns a) If an extension cable is required, use an approved triple core extension cable suitable for a) Provide information about the risk to eyes at the power input of the tool.
  • Page 8 SYMBOLS AND POWER RATING CHART Danger! – Read the operating Caution! Wear safety goggles. instructions to reduce the risk of injury. Caution! Risk of Injury! Do Caution! Wear ear defenders. The not reach into the running impact of noise can cause damage saw blade to hearing.
  • Page 9: Machine Details And Product Features

    MACHINE DETAILS AND PRODUCT FEATURES Machine Details Specifications: Specifications: MIG100 MIG130 Mains Voltage - 230V / 50Hz Rated Max. Supply Current - 13A Output Amperage Range @ 48A@60% 50A@60% Duty Cycle – 90A @10% 120A@ 10% No Load Voltage - 27.5V Suitable Size Flux Cored - 0.6-0.9mm...
  • Page 10 MACHINE DETAILS AND PRODUCT FEATURES Product Features Handle Thermostat control lamp Housing cover ON/OFF switch Welding wire speed controller Switch for welding current adjustment Mains plug Earth terminal Hose package 10. Welding nozzle 11. Torch 12. Wire brush 13. Welding screen 14.
  • Page 11: Assembly

    Assembly 3 Inserting the wire spool 1.Fitting the welding screen 1.Unlock the housing cover by turning the 1.Place the welding glass (A) over it in the frame fastening screw through 90° and flip open the for welding screen(B). cover. 2.Check that the windings on the spool do not overlap so as to ensure that the wire can be unwound evenly.
  • Page 12 Assembly 4.Swing the screws (F) 90 °and pull off 9. Push the pressure roller holder(E) upwards and Pull the pressure roller spring(D) and swing it upwards. downward. 5.Check the feed roller (G). The appropriate wire thickness must be specified on the top of the feed roller (G).
  • Page 13 OPERATION Electrical connection Operation -Before you connect the equipment to the mains supply make sure that the data on the rating plate are identical to the mains data. Before any work on the machine itself, remove the mains plug from outlet. -The equipment may only be operated from properly earthed and fused shock-proof sockets.
  • Page 14: Operation, Maintenance And Service

    OPERATION /MAINTENANCE AND SERVICE -Do not remove the slag until the weld has Maintenance and Service cooled. If you want to continue a welding job on an interrupted weld seam, the slag from your Always pull out the mains power plug before initial attempt must first be removed.
  • Page 15: Autojack Guarantee

    In our experience many initial problems with machines that are thought to be fault due to faulty 1.2.3 If asked to do so by Autojack or its parts are actually solved by correct setting up or Authorised Dealer, you return the product at adjustment of the machine.
  • Page 16 Autojack. If you include a contact number with this it will speed your claim up. 2.4 Please note that it is essential that the letter of claim reaches Autojack on the last day of this guarantee at the latest. Late claims will not be considered.
  • Page 17: Declaration Of Conformity

    CE DECLARATION OF CONFORMITY TOOLSAVE Unit C, Manders Ind. Est., Old Heath Road, Wolverhampton, WV1 2RP. Tel: 01902 450 470 Declares that the Welding Maching Mig Master (MIG100/MIG130) Is in compliance with the regulations included in the Directives:2006/42/EC EC DECLARATION OF CONFORMITY Certificate for EC-type examination delivered by AV Technology Ltd.
  • Page 18: Parts List

    Parts List Description Description Screw Handle Potentionmeter Top panel PC board Left panel Welding torch Middle panel Kickstand Wire feed Knob Screw Wire spool holder Overheating indicator light Screw Power switch Spacer Adjustment switch Water joint Rivet Earth clamp Guard ring of torch Plug Transformer Screw...
  • Page 19: Parts Diagram

    Parts Diagram MIG100/MIG130...
