Dynamic Mounting Down And Out Mount Assembly & Installation Directions page 2

CAUTION: These wall mounting instructions and hardware are for mounting to wood
studs only. It is up to you to verify that the material supplied will work for your setup;
other materials may need to be purchased by you. For concrete, brick or other mounting
materials consult an expert.
Consult your television's owner manual before mounting your television, it contains relevant
Tools Needed

7/16 and 1/2 inch box or open ended wrench

9/16 inch box wrench, A ratcheting socket wrench with extension makes the job easier

1/4 inch Drill Bit

Drill

Tape Measure

Stud Finder

Level

Phillips Screwdrivers

A friend or 2, depending on how heavy your television is
Parts Included

1 Down And Out Mount

2 Attach Arms

2 #10 x 7/8 inch long machine screw with washer for mounting the Attach Arms to the Down And Out Mount (These are
threaded into the Attach Arms, you need to remove before attaching TV to attach arms)

2 White Paintable Plastic Covers (Hang these over the Wall Plate to Cover arms, can be painted)
Various Items (All in One Bag)

4 3/8 inch by 3 inch long lag screw with washer

4 Zip Ties

2 Adhesive Rubber Bumpers
Fasteners for Mounting the Television to the Attach Arms (All in One Bag)

4 M6 x 20 mm (.78in) long Phillips head machine screw

4 M6 x 35 mm (1.38in) long Phillips head machine screw

4 M8 x 20 mm (.78in) long Phillips head machine screw

4 M8 x 35 mm (1.38in) long Phillips head machine screw

8 1/4 inch tall plastic spacers

4 1/8 inch tall plastic spacers

4 Steel M6 washers
information.
- 2 –
