Mounting installation kit

The installation kit for the Neptun compact jet stream must be covered with the enclosed building
protection so that all threads are protected. Please mind the installation arrangement. (fig.1)
Film pool/ concrete pool
The built-in pot must be concreted entirely, subsequent foaming is not allowed.
polyester pool
When necessary, an additional supporting foot must be attached.
Styrofoam distance bloc is not necessary.
Installation
The installation kit must be fixed 180 mm below the water surface (fig. 1). The 4 threaded nipples
are used for the subsequent mounting of the nozzle frame (fig. 7). The other threads are used for
flange mounting. With concrete pools only the 4 threaded nipple sleeves are mounted.
Film mounting
Attaching the flat gasket to the built-in pot (fig. 2)
round bracket = sheeting
Mounting the base unit (fig. 3, 4, 5, 6 and 7)
You have to provide an outflow possibility as well as an adequate ventilation to prevent a flooding
of the site. That`s the only way how a trouble-free operation can be guaranteed.
The air valve must be mounted vertically upwards and above the water surface. All the required
pipe fittings are included. Should, however, extensions may be necessary, keep the pneumatic
hose as short as possible (max. 4 m), and don`t crincle or clamp it in any way.
Compact 950 and 1200
The pneumatic hose must be placed and fixed on the control box as well as on the buit-in pot.
